Default charlies turbo build

Hey guys thought id start a build thread on this forum..

Ok so i bought the car stock in feb this year.. Its a 1990 1.6 with 5speed.
Original plans were to improve the handling a little and just keep it as a nice daily.. that changes later on

Feb:
Bought axis oldschool wheels, bc coilovers, new gear boots and replaced the broken rear window.
Then the engine blew so replace with a 1.6 longnose, new clutch, new mounts, fix the thermo fans and sort out some wiring.

Heres the first 'look' i went for.


March:
Bought a sparco sprint off a mate.. Went really well and was a good upgrade

Also bought a mania cold air intake and garage vary lip





Detailed the car, bought some new door cards and some project kics spacers







April:
Bought a nardi classic 330mm, mazdaspeed oil cap and m2 runabout mirrors

Painted the valve cover white with red lettering


May
Bought some boss frog 'frog arms', 15mm spacers and secret element tie rods


Fitted the new mirrors
charlie_91 is offline   Reply With Quote
Old 12-26-2010, 06:39 AM   #2
Junior Member
Thread Starter

Join Date: Dec 2009
Posts: 110
Total Cats: 28
Default

June
Installed the frog arms

Bought a local roll bar and got it fitted





Bought a flyin miata rear subframe brace, arc intake and an oil catch can.

Fitted both intakes, new brake pads, fitted subframe brace, tie rods and spacers

IMG]http://img24.imageshack.us/img24/5823/25062010187.jpg[/IMG]





hit up a meet with the new shizz


July:
went to a few meets, replaced the headlights and bought an autokonexion carbon bootlip spoiler





August:
Lowered the car and fitted the rear spoiler.





Bought some sway bars, decided to only fit the front for the time being.. Made up a bmc stopper out of the strut brace


September:
Bought a jackson racing cold air intake and went to a car show..


Bought an exhaust to use as a base and also some boss frog frame rails


Pic:

JDMST September 2010 by Matyas Fulop, on Flickr

Fitted the jr cai and some tuckin 99 floor mats


charlie_91 is offline   Reply With Quote
Old 12-26-2010, 06:39 AM   #3
Junior Member
Thread Starter

Join Date: Dec 2009
Posts: 110
Total Cats: 28
Default

October:
Full custom exhaust with stainless headers (wrapped) and stainless cat.

Bought a barchetta console and some rota grid v's
Name:  7.jpg
Views: 191
Size:  150.3 KB
Name:  6small.jpg
Views: 73
Size:  211.4 KB



This might look familiar



Artech manifold and dp courtesy or slutz

November
Bought some vented window things..


made a list of what to buy and what not..

Engine/Drivetrain-
Forged and balanced bottom end.
Refreshed and decked Head
Thicker Headgasket
HD Clutch Kit (pressure plate, street disc)
1.8 torsen diff
NB8B brakes all round

Fuel & Ignition-
RX-7 550cc Injectors (can get some off a mate)
Upgraded fuel pump

Engine Management-
Haltech Premium Sprint 500 ECU
water temp gauge
Boost gauge
Oil temp gauge
Oil pressure gauge

Turbo -
GT2554r turbo (Oil and water cooled) internally gated
Stainless Steel Manifold
Custom 3" Downpipe
Oil and water line kit
Custom intercooler setup

Exterior -
Work equip 03's 15 x 9 +10 (ordered)
Full respray

Installed a new softop.. that was ******* hard lol And bought a new sparco to replaced the old one..




Turbo parts arrived from the states..


Sold the roll bar and bought a cusco 7pt cage from japland. Also test fitted mates equip 01's and bought another mates takata harness




charlie_91 is offline   Reply With Quote
Old 12-26-2010, 06:40 AM   #4
Junior Member
Thread Starter

Join Date: Dec 2009
Posts: 110
Total Cats: 28
Default

December:

Equips came

wheels on XD







Bought a haltech ecu and then took some better pics



Uploaded with ImageShack.us



Uploaded with ImageShack.us



Uploaded with ImageShack.us

and thats it for now.. Still piecing together the turbo kit.. Still have to buy intercooler, piping, injectors, engine stuff and diff.

Hoping to get the turbo sorted out by march.
charlie_91 is offline   Reply With Quote
Old 12-26-2010, 06:41 AM   #5
Junior Member
Thread Starter

Join Date: Dec 2009
Posts: 110
Total Cats: 28
Default








Just put a deposit on a OS Giken super single clutch and flywheel and just bought an intercooler

heres whats left:
nb6 engine
1.8 diff setup with 4.3 torsen
clutch (soon to be bought)
fuel system (injectors and fuel pump)
cooler piping and BOV.
oil cooler kit (ideas?? make one myself or buy a kit??)
full respray with new panels

Thats pretty much it i think. if anyone can recommend me buying anything that'd be much appreciative.

hope u like it so far
charlie_91 is offline   Reply With Quote
