Old 08-05-2008, 11:34 AM   #161
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,833
Total Cats: 1,786
Default

I know with the Advance Auto ones I've bought, the plunger simply didn't seat well. I could blow through it with my mouth. That's about 2psi. With an air compressor hooked up at 15psi, sometimes it would seal, sometimes it would leak fairly heavy. I bought (what i think is the GTX one) from Rosenthal and it would always seal and has yet to fail on me. I had one from advance fail to operate at all within a few hundred miles.
Braineack is offline   Reply With Quote
Old 08-05-2008, 12:38 PM   #162
Elite Member
iTrader: (30)

Join Date: Aug 2007
Location: Va Beach
Posts: 7,282
Total Cats: 0
Default

So for those of us who are less concerned with being eco friendly, whats the easiest/most simple setup? Currently I have a gutted pcv with a filter and capped the breather side. The car runs just fine. The only issue I have is I get some oil coming out from the pcv side with the filter which I plan to make a catch can for.
__________________
Best Car Insurance | Auto Protection Today | FREE Trade-In Quote
levnubhin is offline   Reply With Quote
Old 08-05-2008, 12:54 PM   #163
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,833
Total Cats: 1,786
Default

like i've stated before: pcv and breather line into a catch can with a huge atmospheric port.
Braineack is offline   Reply With Quote
Old 08-05-2008, 01:35 PM   #164
Junior Member

Join Date: Feb 2007
Location: 11368 miles from where i would like to be
Posts: 269
Total Cats: 92
Default

Quote:
Originally Posted by Braineack View Post
oh give me a break, go suck on a pcv.
Name:  100_8620.jpg
Views: 1
Size:  50.7 KB

Sure thing! :

http://www.youtube.com/watch?v=mhbZBefwbtQ (not finished loading at the time of posting, but couldn't be bothered waiting anymore)

Sealed perfectly at ~2psi and held vacuum very well in the opposite direction, however flowed nicely with vacuum applied from the intake side :-p

Just as it should be, boost or no boost. Stop buying CHEAP JUNK PIECE OF **** RIP OFF COPY CHINESE MADE USELESS PCVs from your local retail outlet and stick genuine Mazda parts in there. For stuff that matters there is no substitute (cept possibly nissan or toyota parts instead)! Ditto radiator caps, ditto thermostats.

Article is 3/4 done, I'll post a link later or tomorrow when I'm happy with it and have moved it to a public location.

Fred.
rb26dett is offline   Reply With Quote
Old 08-05-2008, 01:42 PM   #165
Elite Member
iTrader: (30)

Join Date: Aug 2007
Location: Va Beach
Posts: 7,282
Total Cats: 0
Default

Sorry man, but the pic is just way gay.
__________________
Best Car Insurance | Auto Protection Today | FREE Trade-In Quote
levnubhin is offline   Reply With Quote
Old 08-05-2008, 01:44 PM   #166
y8s
2 Props,3 Dildos,& 1 Cat
iTrader: (8)

y8s's Avatar

Join Date: Jun 2005
Location: Fake Virginia
Posts: 19,038
Total Cats: 406
Default

Fred, stop being a condescending jerk.

Mazda OEM PCV valves for the miata are what most people buy. The OEM GTX valve is what everyone buys after the Miata-specific ones fail.
y8s is offline   Reply With Quote
Old 08-05-2008, 01:50 PM   #167
Junior Member

Join Date: Feb 2007
Location: 11368 miles from where i would like to be
Posts: 269
Total Cats: 92
Default

Quote:
Originally Posted by y8s View Post
The OEM GTX valve is what everyone buys after the Miata-specific ones fail.
Exactly what was the failure mode, and where is the tell tale that it was the PCV failing? Link please ;-)
rb26dett is offline   Reply With Quote
Old 08-05-2008, 01:53 PM   #168
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,833
Total Cats: 1,786
Default

being black flagged on the track.....that was my tell tale sign.


now throw a handy vac on the IM side pulling about -10psi
Braineack is offline   Reply With Quote
Old 08-05-2008, 02:00 PM   #169
Elite Member
iTrader: (7)

samnavy's Avatar

Join Date: Apr 2006
Location: VIRGINIA BEACH, VA
Posts: 6,020
Total Cats: 175
Default

The plunger side of the valve fails and the plastic housing itself comes apart... pics are not for the weak of heart:
https://www.miataturbo.net/forum/showthread.php?t=9920
samnavy is offline   Reply With Quote
Old 08-05-2008, 02:07 PM   #170
Elite Member
iTrader: (3)

AbeFM's Avatar

Join Date: Aug 2006
Location: San Diego, CA
Posts: 3,048
Total Cats: 8
Default

Quote:
Originally Posted by m2cupcar View Post
I believe the drawing below illustrates the general consensus on a crank case vent system adequate to manage boost blow by and still remain somewhat eco-friendly.
I'm not sure I like the VTA in the catch can. Technically, it shouldn't hurt anything, but again, there's no reason to not collect that stuff. Compared to the 50/50 by volume gasoline you're spraying in, you won't make any real difference to how the motor runs. If you were burning much of it, the OEM wouldn't pass smog with a system like PCV in. :-)

Im pretty sure the green "breather" is far and away the BIGGEST restriction in the entire system, pluming the catch can to the turbo inlet is fine and not going to be the limiting factor.

Also, doing it as shown will want a filter on the VTA since you're going to suck some into your motor through there. Well, not likely, but in theory. The other way, everything's already a closed system.

Fred, you should go as PCV testing guy for halloween. I noticed sucking on my own PCV that with a little touch on the back of the punger, it would seal in the other direction. Call it 5 psi?
AbeFM is offline   Reply With Quote
Old 08-05-2008, 02:10 PM   #171
Elite Member
iTrader: (3)

AbeFM's Avatar

Join Date: Aug 2006
Location: San Diego, CA
Posts: 3,048
Total Cats: 8
Default

Good lord, did I not get the right PCV valve? I ordered the part number from the picture of the PCV valve showed earlier in this thread, and it came and was plastic. I just figured, well, the GTX one was plastic...
AbeFM is offline   Reply With Quote
Old 08-05-2008, 02:16 PM   #172
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,833
Total Cats: 1,786
Default

I've never seen one "GTX" look the same....and this is from mazda....ill have to look at mine again. I just know i have a factory valve, and it's fine.
Braineack is offline   Reply With Quote
Old 08-05-2008, 02:16 PM   #173
Junior Member

Join Date: Feb 2007
Location: 11368 miles from where i would like to be
Posts: 269
Total Cats: 92
Default

LOL, nice work. Still, the part where it is bonded together is still intact. Plastic mouldings (like pistons) don't just snap in half by themselves and boost applied from the end axially simply would not have the required force to exceed the yield strength of the part in that fashion. I'd place a small wager that you or a mate leaned on it inadvertently at some point. Most plastic radiator tanks die that same way too. How many others have had this exact failure?

For y8s :

Quote:
Get a factory part...I had to buy 3 NAPA valves to get one that I couldn't blow through myself.
I rest my "buy OEM" case!

Brain, pissing oil into the intake doesn't say "failed PCV" to me, it could have been, but it could have been other things too. Which of the two possible ways was it heading into your engine?

Fred.
rb26dett is offline   Reply With Quote
Old 08-05-2008, 02:24 PM   #174
y8s
2 Props,3 Dildos,& 1 Cat
iTrader: (8)

y8s's Avatar

Join Date: Jun 2005
Location: Fake Virginia
Posts: 19,038
Total Cats: 406
Default

Quote:
Originally Posted by rb26dett View Post
For y8s :



I rest my "buy OEM" case!
where'd you even quote that from? samnavy used his stock valve and it died.
y8s is offline   Reply With Quote
Old 08-05-2008, 02:46 PM   #175
Elite Member
iTrader: (7)

samnavy's Avatar

Join Date: Apr 2006
Location: VIRGINIA BEACH, VA
Posts: 6,020
Total Cats: 175
Default

^He's saying that particular kind of failure isn't possible and that I probably leaned on it at one time or another with my hand and cracked it... which I can't dispute. All I do know is that my stock OEM naturally aspirated Miata PCV valve broke and almost cost me an engine... and my Advance autoparts Mazda 323GTX Bosch part is still going strong. My case is not unique as a search will reveal.

FWIW, the Miata and 323 part numbers are different for all manufacturers... not just the OEM Mazda one.

Sometime this week I'll hit HomeDepot and get the parts for an M2cupcar designed catch-can and route it in the manner detailed above. I'll let everbody know how it works out.

I've been wanting to do this for a long time and this thread is just the impetus I need.
samnavy is offline   Reply With Quote
Old 08-05-2008, 02:48 PM   #176
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,833
Total Cats: 1,786
Default

I wanna falcon punch someone....
Braineack is offline   Reply With Quote
Old 08-05-2008, 02:51 PM   #177
Junior Member

Join Date: Feb 2007
Location: 11368 miles from where i would like to be
Posts: 269
Total Cats: 92
Default

Quote:
Originally Posted by y8s View Post
where'd you even quote that from? samnavy used his stock valve and it died.
Try page 2 ;-)

Sam, do you agree? It looks like it was cracked by sideways pressure. I myself have wiggled them sideways with great force to get them out on occasion, it could exactly that behaviour which broke it. Or perhaps the lean thing. What do you think?

When I prompted for that I was 50/50 expecting someone to post pics of the bonding coming loose and it literally falling in half. If that happens, to Mazda units, made in Japan, not NA, then I'll bite my tongue a little more. But, I strongly doubt it. The GTX isn't the only boosted car out of japan, they all have PCVs on them, all are SO similar in design and construction. And unless they are faulty or dirty they will all hold backwards pressure to some extent just fine.

Fred.
rb26dett is offline   Reply With Quote
Old 08-05-2008, 03:12 PM   #178
Elite Member
Thread Starter
iTrader: (5)

m2cupcar's Avatar

Join Date: Jan 2005
Location: Atlanta
Posts: 7,236
Total Cats: 288
Default

I haven't used a GTX valve yet. But I can say that every OE stock Miata valve I've tried (five) leaks over 10psi. Under that they are fine. I've had one autozone cheapy that wouldn't hold back more than a couple of psi. I had another noname for a supra that worked for about 500 miles and the started leak over 10psi.

Abe- that hose at the bottom is a drain, not VTA. The vent line is what runs to the intake. I'll update the image and label that.
m2cupcar is offline   Reply With Quote
Old 08-05-2008, 03:39 PM   #179
Junior Member

Join Date: Feb 2007
Location: 11368 miles from where i would like to be
Posts: 269
Total Cats: 92
Default

I remember asking you this before, but tell me again how you tested them to prove that they leaked? Perhaps Miata ones just suck? If I can find some compressed air I'll try to test this Toyota one.

I've finished the article, feel free to rip it to shreds. Literally, be as hard and critical as you like. I'm devoid of feelings to hurt anyway ;-)

http://www.diyefi.org/forum/viewtopic.php?f=24&t=357

Hopefully it goes a long way to making sure I never type about this stuff again...

Fred.
rb26dett is offline   Reply With Quote
Old 08-05-2008, 03:41 PM   #180
Elite Member
iTrader: (3)

AbeFM's Avatar

Join Date: Aug 2006
Location: San Diego, CA
Posts: 3,048
Total Cats: 8
Default

M2: Oh, ah! Ok, then yes I like it! I sortof thought it was WAY too schematic to have a hose off the bottom. :-P

So why no baffles? You don't like the steel wool since you don't want to steel wool your engine internals? I could see that. I doubt a simple baffle will some anywhere NEAR working as well.

Probably one long coiled rope/wire would be good. In high reliability applications I've seen all sorts of things makes that way. But I don' think flat surfaces are going to catch much.

Quote:
Originally Posted by samnavy View Post
Sometime this week I'll hit HomeDepot and get the parts for an M2cupcar designed catch-can and route it in the manner detailed above. I'll let everbody know how it works out.

I've been wanting to do this for a long time and this thread is just the impetus I need.
Same for me, I have the can and lacked a plan. Now, with both in hand, I'm sure the outcome will be grand.
AbeFM is offline   Reply With Quote
