Maxed out injectors - Miata Turbo Forum - Boost cars, acquire cats.

Welcome to Miataturbo.net   Members



DIY Turbo Discussion greddy on a 1.8? homebrew kit?

Reply



LinkBack Thread Tools
Old 11-27-2014, 02:51 PM   #1
Junior Member
Thread Starter

Join Date: Aug 2014
Location: Pleasant grove, utah
Posts: 51
Total Cats: -3
Default Maxed out injectors

So I've tried searching and can't find the answer to my question. What does it feel like to max out your injectors? Is there a physical feeling in the engine? The reason I ask is, if I wot I get to 4000 rpm and car doesn't go faster. Speed stays the same and Rpms stay around 4000. It kind of seems like a slipping clutch. If it was the clutch slipping, wouldn't the rpms rev higher? If I'm easy on the throttle it drives normal. So Would this be what maxing out injectors "feel" like? Or something else?
Claybay09 is offline   Reply With Quote
Old 11-27-2014, 03:08 PM   #2
Elite Member

codrus's Avatar

Join Date: Mar 2007
Location: Santa Clara, CA
Posts: 3,875
Total Cats: 344
Default

Quote:
Originally Posted by Claybay09 View Post
So I've tried searching and can't find the answer to my question. What does it feel like to max out your injectors? Is there a physical feeling in the engine? The reason I ask is, if I wot I get to 4000 rpm and car doesn't go faster. Speed stays the same and Rpms stay around 4000. It kind of seems like a slipping clutch. If it was the clutch slipping, wouldn't the rpms rev higher? If I'm easy on the throttle it drives normal. So Would this be what maxing out injectors "feel" like? Or something else?
Finding a maxed out injector is easy -- data log the ECU and look at the max duty cycle you've used.

Maxed out fuel pumps manifest as a lean spot that doesn't go away when you increase the injector duty cycle in those zones.

--Ian
codrus is offline   Reply With Quote
Old 11-27-2014, 03:20 PM   #3
Junior Member
Thread Starter

Join Date: Aug 2014
Location: Pleasant grove, utah
Posts: 51
Total Cats: -3
Default

The only problem is im on aids. Maybe I should have mentioned that. So no ecu
Claybay09 is offline   Reply With Quote
Old 11-27-2014, 03:42 PM   #4
Senior Member
iTrader: (1)

Onyxyth's Avatar

Join Date: May 2013
Location: Boyertown, PA
Posts: 719
Total Cats: 55
Default

Maxing out your injectors feels like looking at your wideband and seeing your AFRs going too lean

Edit: you said you're on band aids, do you have a wideband at all?

Last edited by Onyxyth; 11-27-2014 at 04:59 PM.
Onyxyth is offline   Reply With Quote
Old 11-27-2014, 05:48 PM   #5
Junior Member
Thread Starter

Join Date: Aug 2014
Location: Pleasant grove, utah
Posts: 51
Total Cats: -3
Default

I'm working on it
Claybay09 is offline   Reply With Quote
Old 11-27-2014, 05:53 PM   #6
Senior Member
iTrader: (2)

williams805's Avatar

Join Date: Oct 2013
Location: Goleta, Southern California
Posts: 510
Total Cats: 25
Default

Attached Thumbnails
Maxed out injectors-a6c8c220-d31b-4461-bdda-ba4d2c0b21f3.jpg
williams805 is offline   Reply With Quote
Old 11-27-2014, 08:45 PM   #7
Moderator
iTrader: (11)

sixshooter's Avatar

Join Date: Nov 2008
Location: Tampa, Florida
Posts: 15,624
Total Cats: 1,559
Default

Maxing out your injectors feels like detonation in boost and a loss of power that accompanies the pistons and rings breaking. What does your wideband say when the car stops accelerating?
sixshooter is offline   Reply With Quote
Old 11-27-2014, 09:02 PM   #8
Slowest Progress Ever
iTrader: (26)

thirdgen's Avatar

Join Date: Oct 2007
Location: The coal ridden hills of Pennsylvania
Posts: 5,805
Total Cats: 183
Default

Wideband? Who needs a wideband?
thirdgen is offline   Reply With Quote
Old 11-27-2014, 10:23 PM   #9
Junior Member
Thread Starter

Join Date: Aug 2014
Location: Pleasant grove, utah
Posts: 51
Total Cats: -3
Default

God damn noobs!
Claybay09 is offline   Reply With Quote
Old 11-28-2014, 03:00 PM   #10
Junior Member
Thread Starter

Join Date: Aug 2014
Location: Pleasant grove, utah
Posts: 51
Total Cats: -3
Default

Or could it possibly be spark blow out?
Claybay09 is offline   Reply With Quote
Old 11-28-2014, 03:48 PM   #11
Elite Member
iTrader: (8)

Ryan_G's Avatar

Join Date: Jan 2012
Location: Tampa, Florida
Posts: 2,574
Total Cats: 151
Default

It could also be the fuel pump dieing
Ryan_G is online now   Reply With Quote
Old 11-28-2014, 06:30 PM   #12
Junior Member
Thread Starter

Join Date: Aug 2014
Location: Pleasant grove, utah
Posts: 51
Total Cats: -3
Default

Don't worry wideband is in the mail!
Claybay09 is offline   Reply With Quote
Old 11-28-2014, 07:48 PM   #13
Junior Member

Join Date: Jan 2014
Location: Port Saint Lucie,FL
Posts: 418
Total Cats: 3
Default

Plugged up cats could do this as well (if you have one)
Mech5700 is offline   Reply With Quote
Old 11-28-2014, 07:59 PM   #14
Moderator
iTrader: (11)

sixshooter's Avatar

Join Date: Nov 2008
Location: Tampa, Florida
Posts: 15,624
Total Cats: 1,559
Default

Who turbos without a wideband? That's not good.
sixshooter is offline   Reply With Quote
Old 11-28-2014, 08:09 PM   #15
Junior Member
Thread Starter

Join Date: Aug 2014
Location: Pleasant grove, utah
Posts: 51
Total Cats: -3
Default

Apparently dumb *** noobs with no money and couldn't wait. Now feeling the consequences. I'm just waiting for the " I told you so noob!" Haha
Claybay09 is offline   Reply With Quote
Old 11-28-2014, 09:54 PM   #16
Moderator
iTrader: (11)

sixshooter's Avatar

Join Date: Nov 2008
Location: Tampa, Florida
Posts: 15,624
Total Cats: 1,559
Default

I would never.
sixshooter is offline   Reply With Quote
Old 01-02-2015, 08:39 PM   #17
Junior Member
Thread Starter

Join Date: Aug 2014
Location: Pleasant grove, utah
Posts: 51
Total Cats: -3
Default

So I finally have a wideband and a boost gauge. When this "happens" AFR goes full lean when I'm at 8 psi, which is what the internal wastegate is. My aids are as follows: msd retard box, stock 1.8 tan top injectors, and a 1:8 fmu. Also idle is stupid rich between 11.5-12.5.
Claybay09 is offline   Reply With Quote
Old 01-02-2015, 10:35 PM   #18
Junior Member

Join Date: Jan 2014
Location: Port Saint Lucie,FL
Posts: 418
Total Cats: 3
Default

How have you not melted anything yet?
Mech5700 is offline   Reply With Quote
Old 01-02-2015, 10:58 PM   #19
Ben
Supporting Vendor
iTrader: (33)

Ben's Avatar

Join Date: Jul 2006
Location: atlanta-ish
Posts: 12,689
Total Cats: 99
Default

Quote:
Originally Posted by Claybay09 View Post
So I finally have a wideband and a boost gauge. When this "happens" AFR goes full lean when I'm at 8 psi, which is what the internal wastegate is. My aids are as follows: msd retard box, stock 1.8 tan top injectors, and a 1:8 fmu. Also idle is stupid rich between 11.5-12.5.
Is your FMU hooked up to a good vac/boost reference? Kinda sounds like its pressure port is open to atmosphere. You need a fuel pressure gauge.
Ben is offline   Reply With Quote
Old 01-02-2015, 11:19 PM   #20
Junior Member
Thread Starter

Join Date: Aug 2014
Location: Pleasant grove, utah
Posts: 51
Total Cats: -3
Default

Yes the extra nipple on the im, right after the tb.

Last edited by Claybay09; 01-02-2015 at 11:32 PM. Reason: Photo fail
Claybay09 is offline   Reply With Quote
