Default Oil Pump Gasket - Dumb question

Easy question for the day.... Not for me apparently. Is there a gasket between the oil pump and block? Can't find anything in the manual that says anything about a gasket or RTV.

thanks in advance.
thymer is offline   Reply With Quote
Old 09-18-2008, 04:07 PM   #2
Junior Member

Join Date: Aug 2007
Posts: 115
Total Cats: 0
Default

yes
yertnamreg1218 is offline   Reply With Quote
Old 09-18-2008, 04:16 PM   #3
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,872
Total Cats: 1,790
Default

the service manual shows the need to remove and replace the gasket
Braineack is offline   Reply With Quote
Old 09-18-2008, 05:12 PM   #4
Senior Member
Thread Starter
iTrader: (5)

Join Date: Apr 2008
Location: VA
Posts: 828
Total Cats: -2
Default

Quote:
Originally Posted by Braineack View Post
the service manual shows the need to remove and replace the gasket
My 1994 Mazda service manual shows no gasket. I talked to Mazda motorsports and they said no gasket on the '94. RTV, o-ring, but no gasket. FM says the same thing. No gasket on the mazda parts breakdown. weird.
thymer is offline   Reply With Quote
Old 09-18-2008, 05:47 PM   #5
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,872
Total Cats: 1,790
Default

well then. you has fsm in psd?
Braineack is offline   Reply With Quote
Old 09-18-2008, 06:10 PM   #6
Senior Member
Thread Starter
iTrader: (5)

Join Date: Apr 2008
Location: VA
Posts: 828
Total Cats: -2
Default

Quote:
Originally Posted by Braineack View Post
well then. you has fsm in psd?
huh? Speak frickin english man!

I'm pretty sure when I took that thing off there was a gasket....
thymer is offline   Reply With Quote
Old 09-19-2008, 08:29 AM   #7
Junior Member
iTrader: (1)

Join Date: Jun 2008
Location: Atlanta, GA
Posts: 157
Total Cats: 0
Default

FSM = Factory Service Manual
PDF = Portable Document Format (Adobe owns this)
quadmasta is offline   Reply With Quote
Old 09-19-2008, 09:15 AM   #8
Senior Member
Thread Starter
iTrader: (5)

Join Date: Apr 2008
Location: VA
Posts: 828
Total Cats: -2
Default

Quote:
Originally Posted by quadmasta View Post
FSM = Factory Service Manual
PDF = Portable Document Format (Adobe owns this)
Gotcha. I got the FSM part but got thrown off by the PSD. Anyway, upon looking closely at the oil pump there really is no need for the gasket and in fact if the gasket was too thick it could reduce the effectiveness of the o-ring. I'll do a very thin coat of RTV and be done with it.

thanks!
thymer is offline   Reply With Quote
Old 09-19-2008, 09:40 AM   #9
Junior Member
iTrader: (1)

Join Date: Jun 2008
Location: Atlanta, GA
Posts: 157
Total Cats: 0
Default

I recommend using some Indian Head gasket shellac.
quadmasta is offline   Reply With Quote
Old 09-19-2008, 10:04 AM   #10
Junior Member

Join Date: Sep 2008
Posts: 79
Total Cats: 0
Default

make sure you use the oil resistant RTV, as there are many different kinds. The oil resistant is black i believe.
jc_rotor is offline   Reply With Quote
Old 11-29-2008, 11:09 PM   #11
Elite Member
iTrader: (33)

RotorNutFD3S's Avatar

Join Date: Jan 2007
Location: Newnan, GA
Posts: 2,539
Total Cats: 29
Default

Sorry to dredge up an old thread, but I was reading in my '95 FSM about replacing this gasket. When I took the motor apart, I cannot for the life of me remember taking one off, nor can I find one in the labeled bags of everything I took off. But here's the picture of the FSM page:

Name:  OilPanGasket.jpg
Views: 184
Size:  33.5 KB

Anyway, get a gasket, leave it off, or use some RTV?
RotorNutFD3S is offline   Reply With Quote
Old 11-30-2008, 11:54 PM   #12
Senior Member
iTrader: (14)

Join Date: Jan 2007
Location: Murfreesboro,TN
Posts: 1,277
Total Cats: 53
Default

There isn't a gasket for the oil pump to block. I used RTV on mine when I rebuilt my motor 2 years ago without a problem. Recently I picked up a tube of Toyota Gasket Maker and it seems to be a better option than RTV b/c it stays more pliable.

The gasket pointed out in your picture is for the water pump.
Midtenn is offline   Reply With Quote
Old 12-01-2008, 12:25 AM   #13
Guest
iTrader: (6)

Join Date: Sep 2007
Location: Vaughan, On, Canada
Posts: 1,092
Total Cats: 0
Default

I always used Ultra Black on all my old built engines. No issues!
M-Tuned is offline   Reply With Quote
Old 12-01-2008, 01:30 AM   #14
Elite Member
iTrader: (33)

RotorNutFD3S's Avatar

Join Date: Jan 2007
Location: Newnan, GA
Posts: 2,539
Total Cats: 29
Default

Quote:
Originally Posted by Midtenn View Post
The gasket pointed out in your picture is for the water pump.
lol My mistake.
RotorNutFD3S is offline   Reply With Quote
Old 12-01-2008, 11:43 PM   #15
Senior Member
iTrader: (14)

Join Date: Jan 2007
Location: Murfreesboro,TN
Posts: 1,277
Total Cats: 53
Default

Quote:
Originally Posted by RotorNutFD3S View Post
lol My mistake.
No problem, I looked at it a few times to make sure myself.
Midtenn is offline   Reply With Quote
Old 06-03-2013, 01:55 PM   #16
Senior Member
iTrader: (2)

Join Date: Oct 2011
Location: Hickory, NC
Posts: 683
Total Cats: 3
Default

Hate to bring this back from the dead but I was searching for opinions on this and found this thread......That's right noobers, SEARCH!!!

Anyway, the pic shows two gaskets. I ordered part number B621-14-113 directly from Mazda and got the thin paper gasket that goes between the oil pump and block. Just wanting to make sure our archives have accurate information for the next person.
Amellrotts is offline   Reply With Quote
Old 06-03-2013, 02:05 PM   #17
Supporting Vendor
iTrader: (31)

Savington's Avatar

Join Date: Nov 2006
Location: Sunnyvale, CA
Posts: 14,366
Total Cats: 1,326
Default

1.6 is a gasket. 1.8 is RTV and an o-ring at the high-pressure port.
Savington is online now   Reply With Quote
Old 06-03-2013, 02:07 PM   #18
Senior Member
iTrader: (2)

Join Date: Oct 2011
Location: Hickory, NC
Posts: 683
Total Cats: 3
Default

hmmmmm, I ordered a gasket for 1.8 and they sent it, it fits?
I know the last couple engines (1.8s) I have only used Hondabond and have not had any trouble. When ordering the final seals needed for MY engine I asked about the OP gasket and they gave me that part number and it fits well. Now Sav has me second guessing myself. My gut tells me to go with the known entity and use the RTV.
Amellrotts is offline   Reply With Quote
Old 06-03-2013, 02:44 PM   #19
Elite Member
iTrader: (3)

Join Date: Mar 2008
Location: Granbury, TX
Posts: 6,009
Total Cats: 583
Default

Quote:
Originally Posted by Savington View Post
1.6 is a gasket. 1.8 is RTV and an o-ring at the high-pressure port.
In general, this is the right answer. However, I've "heard" that some of the early 1.8s used a gasket.

Safest approach is to look at the back of your oil pump. Inspect the surface that meets the engine block.

If it looks like this, you need a gasket (ignore the circles please):


If it looks like this, you need an O-ring and oil-resistant RTV:


General rule, surfaces that take gaskets are always flat. Surfaces that take RTV will have a machined groove. And, obviously, an O-ring needs a machined groove as well.
Attached Thumbnails
Oil Pump Gasket - Dumb question-oil-pump-o-ring.jpg
hornetball is offline   Reply With Quote
Old 06-03-2013, 03:00 PM   #20
Senior Member
iTrader: (2)

Join Date: Oct 2011
Location: Hickory, NC
Posts: 683
Total Cats: 3
Default

GREAT POST Hornet!!!!!
Mine was milled for the o-ring as well as the sealing flange for the RTV and that is why I was researching it myself. I will use the Hondabond with confidence.
Amellrotts is offline   Reply With Quote
