Default Setting timing/belt without plate behind cams..

So... putting motor back togetherish and back into car during this build. I pulled the timing belt off the cams for some reason... tried to slip them back on without touching the tensioner and I budged the cams.

Issue is... I don't have the plate behind the cams anymore... and its 1.5hrs away... and I'd prefer to just not run it at this point.

How do I align the crank/cams and such to put the timing belt back on?

I could do this on a honda... but I don't know enough about this motor to do it by secondary methods.

1993 1.6L...

I'm working on this literally now... so any help is super appreciated.
Splitime is offline   Reply With Quote
Old 06-26-2007, 10:14 PM   #2
:(
iTrader: (7)

Join Date: Jul 2006
Location: nowhere
Posts: 8,281
Total Cats: 2
Default

Traditionally when the marks are aligned the other set of marks will be at 12 oclock see this pic courtesy of m.net
magnamx-5 is offline   Reply With Quote
Old 06-26-2007, 10:18 PM   #3
Miotta FTW!
Thread Starter
iTrader: (24)

Splitime's Avatar

Join Date: Jun 2006
Location: Chicagoland, IL
Posts: 4,295
Total Cats: 26
Default

Wonderful. Wish me luck

I really wish I had a shop manual.
Splitime is offline   Reply With Quote
Old 06-26-2007, 10:22 PM   #4
:(
iTrader: (7)

Join Date: Jul 2006
Location: nowhere
Posts: 8,281
Total Cats: 2
Default

just be carefull not to slip the crank around while installing the belt or adding tension. it is a pita, trust me.
magnamx-5 is offline   Reply With Quote
Old 06-27-2007, 12:20 AM   #5
Miotta FTW!
Thread Starter
iTrader: (24)

Splitime's Avatar

Join Date: Jun 2006
Location: Chicagoland, IL
Posts: 4,295
Total Cats: 26
Default

marks aren't wanting to play nice.

I have a tiny dot in the rim of the gear on each.
I also have an E and and I on different spokes.
I also have a notch on both...

What goes where?

Help....
Splitime is offline   Reply With Quote
Old 06-27-2007, 12:28 AM   #6
Ben
Supporting Vendor
iTrader: (33)

Ben's Avatar

Join Date: Jul 2006
Location: atlanta-ish
Posts: 12,689
Total Cats: 99
Default

Ready to slap yourself and say "DUH"?

E = exhaust = driver's side cam
I = intake = pass side cam

hopefully you put a little dot of whiteout to identify position...
Ben is offline   Reply With Quote
Old 06-27-2007, 10:05 AM   #7
:(
iTrader: (7)

Join Date: Jul 2006
Location: nowhere
Posts: 8,281
Total Cats: 2
Default

yeah i forgot about that sorry splittime,
magnamx-5 is offline   Reply With Quote
Old 06-27-2007, 01:37 PM   #8
Miotta FTW!
Thread Starter
iTrader: (24)

Splitime's Avatar

Join Date: Jun 2006
Location: Chicagoland, IL
Posts: 4,295
Total Cats: 26
Default

No dots to mark anything... Was not intending to really remove belt... can't even remember why I was mucking with it.

I'm just so used to a honda... set crank and then u can set cams according to how they align with each other and cams.... so damn simple.

Bah... i put it together... no clue if its even close... I'll take a closer look once rest of car is together.
Splitime is offline   Reply With Quote
Old 06-27-2007, 03:42 PM   #9
Elite Member
iTrader: (3)

Join Date: May 2006
Location: Houston, TX
Posts: 2,900
Total Cats: 0
Default

1) put the pin in the "I" hole on the intake side, and the "E" hole on the exhaust side (if the gears were removed)

2) The "E" on the intake cam should point roughly 30* below horizontal towards the engine centerline

3) the "I" on the exhaust cam should point roughly 30* below the horizontal towards the engine centerline

4) with the cams in that location there should be a tooth on each marked with a dot or a line (on the tooth itself), these should be damn near straight up.

5) To verify that the cams are accurate in relation to each other there should be 19 teeth on the belt between the marked gear teeth.

Now it has been a few months since I've done this so I could be wrong... but I think that's pretty close.
Arkmage is offline   Reply With Quote
Old 10-01-2008, 11:51 PM   #10
Junior Member
iTrader: (1)

Join Date: Jun 2008
Location: Atlanta, GA
Posts: 157
Total Cats: 0
Default

Thanks, old thread!
quadmasta is offline   Reply With Quote
Old 10-02-2008, 12:01 AM   #11
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,892
Total Cats: 1,792
Default

Braineack is offline   Reply With Quote
Old 10-02-2008, 12:12 AM   #12
Junior Member
iTrader: (1)

Join Date: Jun 2008
Location: Atlanta, GA
Posts: 157
Total Cats: 0
Default

I used the search function and found exactly what I needed so I thanked the thread.
quadmasta is offline   Reply With Quote
Old 10-02-2008, 10:49 AM   #13
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

Name:  threadnecromancer.jpg
Views: 1
Size:  68.9 KB
Faeflora is offline   Reply With Quote
Old 10-02-2008, 11:38 AM   #14
Junior Member

Join Date: Sep 2008
Location: Tulsa, Oklahoma
Posts: 350
Total Cats: -1
Default

OMFG LOL. He thanked the thread. I'm so doing that next time.

P.S. I actually needed to know this, and was going to look for related info later this evening. Now I don't have to, and I can just archive it in my "Miata Tech" tab.
944obscene is offline   Reply With Quote
