Where does this go? - Miata Turbo Forum - Boost cars, acquire cats.

Welcome to Miataturbo.net   Members



General Miata Chat A place to talk about anything Miata

Reply



LinkBack Thread Tools
Old 06-13-2010, 04:06 PM   #1
Elite Member
Thread Starter
iTrader: (17)

Join Date: Aug 2007
Location: Fort Myers, FL
Posts: 2,790
Total Cats: 128
Default Where does this go?

I pulled my motor to do a clutch and coolant reroute, when I put it back together I've got a leftover connection and the car is idling at 4000rpms. I'm hoping they're related, ha. For the life of me I can't figure out where this thing goes. It T's off the other harnesses right at the back of the intake manifold. Any ideas?



pdexta is offline   Reply With Quote
Old 06-13-2010, 04:08 PM   #2
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,838
Total Cats: 1,787
Default

looks like o2 connector.
Braineack is offline   Reply With Quote
Old 06-13-2010, 04:09 PM   #3
Elite Member
Thread Starter
iTrader: (17)

Join Date: Aug 2007
Location: Fort Myers, FL
Posts: 2,790
Total Cats: 128
Default

YESSSS!! That's it, awesome. Thanks. I'm an idot.
pdexta is offline   Reply With Quote
Old 06-13-2010, 04:48 PM   #4
Elite Member
iTrader: (4)

Pen2_the_penguin's Avatar

Join Date: Dec 2009
Location: Reno, NV
Posts: 3,690
Total Cats: 97
Default

fail.
Pen2_the_penguin is offline   Reply With Quote
Old 06-13-2010, 05:12 PM   #5
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

Woohoo I recognized it as such too. My miata wrenching skills must be leveling up slowly.
Faeflora is offline   Reply With Quote
Old 06-13-2010, 05:55 PM   #6
Elite Member
iTrader: (7)

Join Date: Jul 2009
Location: Gainesville,Fl
Posts: 3,354
Total Cats: 7
Default

Quote:
Originally Posted by faeflora View Post
Woohoo I recognized it as such too. My miata wrenching skills must be leveling up slowly.
Same here.
turotufas is offline   Reply With Quote
Old 06-13-2010, 06:19 PM   #7
Elite Member
Thread Starter
iTrader: (17)

Join Date: Aug 2007
Location: Fort Myers, FL
Posts: 2,790
Total Cats: 128
Default

So now that that's out of the way, and I've already made an *** of myself... Any ideas on why the car could be idling at 4k?

This is with a MSPNP, on a '99 miata. The car was running fine on the MS and MAP sensor before the motor came out. All that changed was the motor coming out, new clutch going in, and turbo going on. Runs great at 4000rpms, throttle is closed, can't find any vacuum leaks.
pdexta is offline   Reply With Quote
Old 06-13-2010, 07:13 PM   #8
I'm Miserable!
iTrader: (11)

Join Date: Apr 2008
Location: Texas, 'Murica
Posts: 2,505
Total Cats: 7
Default

Plug up the Idle motor?
chicksdigmiatas is offline   Reply With Quote
Old 06-13-2010, 10:18 PM   #9
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

Quote:
Originally Posted by chicksdigmiatas View Post
Plug up the Idle motor?
That's in the front, by the throttle body!
Faeflora is offline   Reply With Quote
Old 06-13-2010, 10:20 PM   #10
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

Quote:
Originally Posted by pdexta View Post
So now that that's out of the way, and I've already made an *** of myself... Any ideas on why the car could be idling at 4k?

This is with a MSPNP, on a '99 miata. The car was running fine on the MS and MAP sensor before the motor came out. All that changed was the motor coming out, new clutch going in, and turbo going on. Runs great at 4000rpms, throttle is closed, can't find any vacuum leaks.
Mad tyte vacuum leak yo!!!
Faeflora is offline   Reply With Quote
Old 06-13-2010, 10:22 PM   #11
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 36,174
Total Cats: 2,575
Default

homosexual vacuum leak
18psi is offline   Reply With Quote
Old 06-13-2010, 10:34 PM   #12
Junior Member
iTrader: (1)

Join Date: Apr 2010
Location: On, Canada
Posts: 81
Total Cats: 1
Default

+1 on the idle air control make sure its all good.
Kris.
uavjeep is offline   Reply With Quote
Old 06-13-2010, 10:46 PM   #13
Elite Member
Thread Starter
iTrader: (17)

Join Date: Aug 2007
Location: Fort Myers, FL
Posts: 2,790
Total Cats: 128
Default

I've had a vacuum leak before and the thing idled at like 1500. This is seriously sitting at like 4300rpms. The Megasquirt is reading 30kpa. If it was a vacuum leak, I should be able to stick my head inside wherever it's leaking.

I unplugged the IAC and plugged it back in, it does the same thing with it plugged or not.
pdexta is offline   Reply With Quote
Old 06-13-2010, 10:47 PM   #14
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

Disconnect that idle air control ************ like crazy yo and turn that bitchass idle screw **** down till your ******* engine dies. If it doesn't you have a mad tyte vacuum leak yo.

Also make sure your throttle cable is not too tight, pulling the throttle plate open.
Faeflora is offline   Reply With Quote
Old 06-13-2010, 10:49 PM   #15
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

Quote:
Originally Posted by pdexta View Post
I've had a vacuum leak before and the thing idled at like 1500. This is seriously sitting at like 4300rpms. The Megasquirt is reading 30kpa. If it was a vacuum leak, I should be able to stick my head inside wherever it's leaking.
Stop being a lazy *** **********-- it is a mad tyte idle leak yo because your engine needs air and fuel to run right? It needs a shitpile of air to run at that high of an RPM. Where is that air coming from? Hmm
Faeflora is offline   Reply With Quote
Old 06-13-2010, 11:00 PM   #16
Elite Member
Thread Starter
iTrader: (17)

Join Date: Aug 2007
Location: Fort Myers, FL
Posts: 2,790
Total Cats: 128
Default

Seriously man, like I said, the throttle is not open. I even took the charge pipes off to check it, it's closed. I've tried turning down the idle screw, doesn't do ****. The ECU and boost gauge are reading hella vacuum. When I had the motor out I did take the intake manifold off to put injectors in, I just find it hard to believe I screwed it up that bad. I'll pressure test it and be back in a few. Thanks for the advise.
pdexta is offline   Reply With Quote
Old 06-13-2010, 11:06 PM   #17
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 36,174
Total Cats: 2,575
Default

Quote:
Originally Posted by pdexta View Post
Seriously man, like I said, the throttle is not open. I even took the charge pipes off to check it, it's closed. I've tried turning down the idle screw, doesn't do ****. The ECU and boost gauge are reading hella vacuum. When I had the motor out I did take the intake manifold off to put injectors in, I just find it hard to believe I screwed it up that bad. I'll pressure test it and be back in a few. Thanks for the advise.
Uh oh. I think I know what your problem may be.

if the throttle is closed/almost closed, and the idle screw does absolutely nothing, its GOT to be a leak at the manifold somewhere.

car can't possibly idle higher without more air.
18psi is offline   Reply With Quote
Old 06-13-2010, 11:13 PM   #18
Senior Member
iTrader: (4)

Join Date: Nov 2009
Location: Toronto, ON
Posts: 1,479
Total Cats: 6
Default

Check for leaks around the injectors.
dgmorr is offline   Reply With Quote
Old 06-13-2010, 11:24 PM   #19
I'm Miserable!
iTrader: (11)

Join Date: Apr 2008
Location: Texas, 'Murica
Posts: 2,505
Total Cats: 7
Default

Brake booster hose, egr, or 1000 vacuum hoses.
chicksdigmiatas is offline   Reply With Quote
Old 06-13-2010, 11:49 PM   #20
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

Faeflora is offline   Reply With Quote
