That is some awesome.



only person I know of that's done anything similar is turbotim.



That setup was awesome, but this will be awesomer.



Commie, I didn't think I could love you anymore than I already do. I learn something new everyday.



So cool. It's like Salvador Dali and MC Escher got together to design a turbo.



Need pics of something to determine scale. Preferably not your enormous *********.



That's insane! Love Schroedinger's description as well.



Well, do you have any information what kind of Mercedes it comes on? We need to figure out what to expect from it now.



My shitty google skills are telling me its off a Sprinter



Looks like the same part to me. The Internet is telling me that the OM651 2.1L engine that it comes on produces 204hp.

I will guess that it can generate 220-260hp bolted to a built BP on pump gas and it will spool super quick. Only one way to know for sure though!



You should be typing up a build thread, right now.



How about this, then?




Man, after all these years, a turbo two turbos, AND a cat...



2008-11 Mercedes Benz C-Class KP39 + K04 Twin Turbo 10009880019

Item# turbo-commercial-mercedes-TC-10009880019
$2,890.00
Availability: Usually ships the next business dayProduct Description

Part Number10009880019Previous Version1000-988-0019, 10009880007OE number6510900080, 6510902380, A6510900080, A6510902380, 6510903280, A6510903280, A6510901280, 6510901280, 0020206000, 0020206100Year2008-11DescriptionR2S Twin TurboManufacturer Part Number10009700019, 10009700007, 1000-970-0019, 1000-970-0007CHRAN/ATurbo ModelKP39.0074 + K04.0094EngineOM651DE22LAEngine ManufacturerMercedes Benz C,E,GLK,CLS Sprinter Bi TurboMERCEDES BENZA 651 090 52 80, A6510905280BORG WARNER1000 970 0019. 10009700019Small Turbo54399880099; A6510904080Large Turbo53049880094; A6510902880Engine Model220/250 CDIDisplacement2.2L, 2143 ccmKW125/150RPM Max4200FuelDieselTurbine Housing ARVTGNOTEIntercooler; R2S; KP39-0099 and K04-0094ManufacturerBorg Warner - 3K - Schwitzer, BWTS DEApplications

2008-09 Mercedes Benz 220/250 with OM651DE22LA Engine R2S Turbo

2008- Mercedes Benz C-Class 250 CDI (W204) Engine OM 651 DE 22 LA

2009- Mercedes Benz C-Class 220 CDI (W204) Engine OM 651 DE 22 LA


The owner of the company told me it would run all day at 2.5 Bar.
We'll see I guess.



I need to get my *** to my garage, remove all SC related parts, yank the head and take it to the machine shop to get the valves adjusted first.
Can not get shims over here... Even the dealer service does it this way.
Then I will post a glorious build thread.

Pic thread, so pics of my garage...



Build thread or ban.





I have a layover in Istanbul for 5 hours. will I die?



Only if we're very lucky.





See if you can sneak your way into the Turkish Airlines member lounge. Then sit back and enjoy the awesomeness. After going up for many, many plates of great food.
