Default Jbperf and Frank MX5 Westfield MS2 Questions

I wanted to build an MS2 + Jbperf (for sequential fuel) exactly like Frank's Westfield site. However, he doesn't show the pinout for sequential fuel for the 1.6, only the non-sequential 1.6.

1) Will the pinout/harness change because I'm doing sequential with Jbperf? Or will the pinout/harness remain the same with or without Jbperf?


2) Because Frank's MS2 page isn't really updated anymore, were there any corrections to his build directions?

90-97 MS2 sequential | Frank's Westfield MX5 90-97 MS2 sequential |

Thanks
Attached Thumbnails
Jbperf and Frank MX5 Westfield MS2 Questions-harness_ms2_16_zpsedbc3e00.png   Jbperf and Frank MX5 Westfield MS2 Questions-cleveland-family-guy-1870111-300-300.jpg
kenzo42 is offline   Reply With Quote
Old 12-20-2013, 08:30 AM   #2
mkturbo.com
iTrader: (24)

shuiend's Avatar

Join Date: May 2006
Location: Charleston SC
Posts: 13,780
Total Cats: 1,106
Default

You will have to run 2 additional wires to run your injectors in sequential mode. On the 1.6 Mazda only fired injectors in batch mode. I think 1/4 and 2/3 are wired together, but you will have to double check that.
shuiend is offline   Reply With Quote
Old 12-20-2013, 08:49 AM   #3
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,892
Total Cats: 1,792
Default

If you don't have a '93 California model, then you'll have to run two new wires and hack up your injector harness to run seq. fueling. At that point you should know that you need to wire Inj A - Cly 1, Inj B - Cly 3, Inj C - Cly 4, Inj D - Cly 2, and you shouldn't really need a wiring pinout diagram...


1&3 and 2&4 are wired together currently.
Braineack is offline   Reply With Quote
Old 12-20-2013, 06:22 PM   #4
Senior Member

Join Date: Nov 2007
Location: Belgium
Posts: 939
Total Cats: 59
Default

I think there used to be a pinout, but I just noticed it's not there. I'll see if I can dig it up. But, as already mentioned, it's really just 2 additional wires for the 2 extra injectors. Just 2 lines on a drawing really.

Edit: made one and added it to the instructions

Last edited by WestfieldMX5; 12-20-2013 at 06:40 PM.
WestfieldMX5 is offline   Reply With Quote
Old 12-21-2013, 02:23 AM   #5
Elite Member
Thread Starter
iTrader: (6)

Join Date: Sep 2007
Location: CA
Posts: 1,990
Total Cats: 9
Default

Thanks Frank!!!
kenzo42 is offline   Reply With Quote
Old 12-21-2013, 09:04 AM   #6
Senior Member

Join Date: Nov 2007
Location: Belgium
Posts: 939
Total Cats: 59
Default

Found an error, corrected now.
WestfieldMX5 is offline   Reply With Quote
Old 12-22-2013, 01:16 AM   #7
Elite Member
Thread Starter
iTrader: (6)

Join Date: Sep 2007
Location: CA
Posts: 1,990
Total Cats: 9
Default

Noted. Thank you.
