Default MSPNP cutting out fuel at various loads

Okay so I thought I had it licked. I turned off the OVERRUN settings and that solved my cutting out issue before.Now it seems like something is killing my juice. I replaced the battery and alternator but something is killing them. After a full battery charge on a new battery and good alternator, the car runs fine. After a while running on the road, say 10 minutes, it starts to shut off my fuel at certain rpms while in gear. Out of gear it revs fine. What the heck is going on?


*MSPNP9093 w/boost, no AFM*
hazimwood is offline   Reply With Quote
Old 07-11-2008, 10:06 PM   #2
Elite Member
iTrader: (3)

Mach929's Avatar

Join Date: Oct 2004
Location: lansdale PA
Posts: 2,500
Total Cats: 0
Default

may be unrelated to ms, have you logged these occurances.
Mach929 is offline   Reply With Quote
Old 07-12-2008, 04:33 PM   #3
I'm Miserable!
iTrader: (5)

bryantaylor's Avatar

Join Date: Dec 2006
Location: jacksonville, fl
Posts: 1,720
Total Cats: 0
Default

you HAVE to post a .msq or else no-one can help you.
bryantaylor is offline   Reply With Quote
Old 07-14-2008, 10:11 AM   #4
Supporting Vendor

Matt Cramer's Avatar

Join Date: Sep 2006
Posts: 2,266
Total Cats: 51
Default

A data log would also help. You can even see the battery voltage in the data log which will be helpful diagnosing the charging system.
Matt Cramer is offline   Reply With Quote
Old 07-16-2008, 02:14 PM   #5
Newb
Thread Starter

Join Date: Dec 2005
Location: Miami, fl
Posts: 31
Total Cats: 0
Default

well the charging system is fine according to the REAL TIME Display. I took it for a little spin down the street. It runs great at first, then it starts to cut out and I let up a bit and then it comes back. This is through all the gears, again when in neutral it revs fine.
hazimwood is offline   Reply With Quote
Old 07-16-2008, 02:52 PM   #6
Senior Member
iTrader: (4)

Join Date: Jan 2008
Location: Falls Church, VA
Posts: 1,367
Total Cats: 16
Default

By "cuts out" you mean it runs lean & sputters, or something else? Does it accelerate fine if you romp on it? Could be that your VE table is just lean as **** in the part throttle cells. Have you ever tuned it and did it ever run well when warmed up?

There are plenty of people on this board who are completely fluent in the ways of Megasquirt (not me) but you have to give them something to work with.

POST A LOG AND YOUR MSQ.


Name:  helpmehelpyou.jpg
Views: 2
Size:  18.5 KB
ScottFW is offline   Reply With Quote
Old 07-16-2008, 06:30 PM   #7
Newb
Thread Starter

Join Date: Dec 2005
Location: Miami, fl
Posts: 31
Total Cats: 0
Default

By "cutting out" I mean that it feels like its cutting fuel...no power. Sure, it sputters into it and out of it, but it goes out like a flashlight and when I let go it regains its normal way. I will post my .msq tonite* If I'm allowed back into the garage( you married guys know what I mean).
hazimwood is offline   Reply With Quote
Old 07-17-2008, 01:26 AM   #8
Elite Member
iTrader: (17)

Join Date: May 2007
Location: NY
Posts: 1,614
Total Cats: 2
Default

Quote:
Originally Posted by hazimwood View Post
If I'm allowed back into the garage( you married guys know what I mean).
All to well...


Anyway, dude def post a log/msq so these guys can help you rule out MS related issues... fwiw, with all the quirks my car has, i'd be dead lost without a wb02...u might wanna invest in an Lc-1 or AEM Uego...

Also, like I mentioned your symptoms sounds similar to mine, when my fuel pump took a dump on me...
TonyV is offline   Reply With Quote
Old 07-30-2008, 09:58 PM   #9
Newb
Thread Starter

Join Date: Dec 2005
Location: Miami, fl
Posts: 31
Total Cats: 0
Default

Here is my setup. The datalog is me backing out of the garage, getting on the road and trying to get the car to move, but it was really bad. I had just replaced the fuel pump and everything was going fine, but I believe some rust is screwing me up and clogged a couple of injectors.

Let me know what you think of the actual problem of the engine cutting out around 60-70 KPA (a guess while looking at the laptop while running).

what is wierd is that I took the car out while it was still cold and got into boost (about 6-7psi) and it ran fine for those few minutes that it was cold. I am guessing that the problem lies in the naroowband O2 or some KPA-related function.
Attached Files
File Type: msq MSPNPJuly162008.msq (35.1 KB, 60 views)
File Type: xls datalog1.xls (337.5 KB, 70 views)
hazimwood is offline   Reply With Quote
Old 07-31-2008, 12:16 AM   #10
Junior Member

Join Date: Oct 2007
Location: AC, NJ
Posts: 346
Total Cats: 0
Default

Battery voltage looks OK in the log and the pulsewidths never went below 1.6

This log doesn't show you ever hitting boost. Do you always let off the throttle when it cuts?
compy is offline   Reply With Quote
Old 07-31-2008, 09:31 PM   #11
Newb
Thread Starter

Join Date: Dec 2005
Location: Miami, fl
Posts: 31
Total Cats: 0
Default

Quote:
Originally Posted by compy View Post
Battery voltage looks OK in the log and the pulsewidths never went below 1.6

This log doesn't show you ever hitting boost. Do you always let off the throttle when it cuts?
It will not let me hit boost when its going through its thing...only when its cold. I dont always let off, but I find it especially frustrating to keep pushing it when it doesn't want to go.

Any answers anyone?
hazimwood is offline   Reply With Quote
Old 12-01-2008, 12:06 PM   #12
Newb
Thread Starter

Join Date: Dec 2005
Location: Miami, fl
Posts: 31
Total Cats: 0
Default

Problem Fixed!!

Turns out that my fuel tank was completely rusted over, causing my new fuel pump and filter to get clogged, not to mention the injectors. I replaced the Tank with a a bigger 1994 unit and everything is running great now. Also my spark plugs were fouled and along with that the car is great now. I could literally scoop out piles of rust with my hand. Very nasty.
hazimwood is offline   Reply With Quote
Old 12-01-2008, 12:22 PM   #13
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,872
Total Cats: 1,790
Default

crazy
Braineack is offline   Reply With Quote
Old 12-01-2008, 07:12 PM   #14
Tour de Franzia
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

please do not post pics of the rusty fuel tank.
hustler is offline   Reply With Quote
Old 12-06-2008, 11:21 AM   #15
Newb
Thread Starter

Join Date: Dec 2005
Location: Miami, fl
Posts: 31
Total Cats: 0
Default

here ya go:
hazimwood is offline   Reply With Quote
