Default Should I upgrade my original MSPNP?

I have the original MSPNP. What would be involved for me to upgrade it to a newer version? MS2? MS3? MS3X? Would it be worth the time or money? Since I'm scared (read: LAZY) to do any soldering I would probably pay someone else (Rev/Brain) to do it.


I'm currently running a 1.6 with basic greddy kit. In the very near future I am going to swap a built 1.8 in and a much nicer turbo kit. (EFR 6258 + ARTech Hot Side)


I'm making this thread for myself but also for other noobs that have the same question.

Last edited by jbrown7815; 01-17-2012 at 07:36 PM.
jbrown7815 is offline   Reply With Quote
Old 01-17-2012, 07:32 PM   #2
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 36,185
Total Cats: 2,582
Default

For your current setup: no.
For the greatness you have planned? yes.

ms2 is great and significantly superior to ms1 IMHO
ms3 is *******, and even more so.

More resolution, way more control, etc etc etc.
Going from tuning my diypnp with ms2extra to a few ms1's around here for my buddies, the ms1 was like a dinasour.
18psi is offline   Reply With Quote
Old 01-17-2012, 07:36 PM   #3
Senior Member
Thread Starter
iTrader: (1)

Join Date: Apr 2010
Location: Portales, NM
Posts: 837
Total Cats: 2
Default

Thanks for the answer Vlad. I plan on swapping the 1.8 I'm getting from rharris in the next month I hope. Then save up more money for the turbo setup. I'd like to learn to tune the new to me 1.8 so I can tune the boosted setup once I get it.
jbrown7815 is offline   Reply With Quote
Old 01-18-2012, 01:28 PM   #4
Senior Member
Thread Starter
iTrader: (1)

Join Date: Apr 2010
Location: Portales, NM
Posts: 837
Total Cats: 2
Default

So should I just get a MS3X since it's the best? Or is the X just an add-on card to the MS3?


I'm so confused.
jbrown7815 is offline   Reply With Quote
Old 01-18-2012, 01:58 PM   #5
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,865
Total Cats: 1,790
Default

Braineack is offline   Reply With Quote
Old 04-29-2013, 11:38 PM   #6
Newb

Join Date: Jun 2012
Location: Greenville, SC
Posts: 32
Total Cats: -1
Default

So, maybe I'm an idiot, but from reading this post and the DIY page, isn't the 3.57 board in my MSPNP gen 1 the same main board described above? And, can't I simply pick up a daughtercard and use it to upgrade to MS3? Like I said, I might be missing something here. Thanks in advance for any clarification.
slpstream4 is offline   Reply With Quote
Old 04-30-2013, 12:49 AM   #7
Senior Member

Join Date: Dec 2004
Location: Brisbane, Australia
Posts: 1,272
Total Cats: 32
Default

You might have to move some I/O around and maybe change the way it reads the triggers. Just compare the pinouts on both.
timk is offline   Reply With Quote
Old 04-30-2013, 01:07 AM   #8
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Chicago (Over two miles from Wrigley Field. Fuck the Cubs. Fuck them in their smarmy goat-hole.)
Posts: 26,317
Total Cats: 1,915
Default

Quote:
Originally Posted by slpstream4 View Post
So, maybe I'm an idiot, but from reading this post and the DIY page, isn't the 3.57 board in my MSPNP gen 1 the same main board described above?
Essentially, yes. A few modifications, however these are mostly irrelevant as the MS3X board will replace nearly all of the functions traditionally carried out by the main board (injectors, ignition, idle, cam input, etc).

It's almost a joke that the main board continues to be required in the MS3 era. It's doing little more than physically holding the MS3 CPU in place and supplying it with power and a couple of analog inputs.


Quote:
And, can't I simply pick up a daughtercard and use it to upgrade to MS3? Like I said, I might be missing something here. Thanks in advance for any clarification.
Yup. If you want, you can slap the 3.57 board into an MS3 case, and add an MS3 CPU and MS3X to it.

On the other hand, in doing so you are destroying a perfectly usable MSPnP which could otherwise be sold to someone else, presumably for much more than the trivial price difference between buying a complete MS3 kit and piecing one together with everything except for the main board.
Joe Perez is offline   Reply With Quote
Old 04-30-2013, 04:34 AM   #9
Senior Member

Join Date: Nov 2007
Location: Belgium
Posts: 939
Total Cats: 59
Default

No you're not making this thread for others, you're only making it for yourself you lazy git. Use the search function, it's been asked over and over.
Also don't even think about buying an ecu that cannot be upgraded like the custom firmware built devices and microsquirt based ****.
You will want to upgrade in the future, so get something that can be upgraded. IOW get a MS3X and don't be a ff-ing cheapskate or you'll find yourself in the same situation that you're in now.
If you cannot afford it than wait and save some money until Brain can build you one.
Yes, I'm having a bad hair day.
WestfieldMX5 is offline   Reply With Quote
Old 04-30-2013, 04:44 AM   #10
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Chicago (Over two miles from Wrigley Field. Fuck the Cubs. Fuck them in their smarmy goat-hole.)
Posts: 26,317
Total Cats: 1,915
Default

Quote:
Originally Posted by WestfieldMX5 View Post
(hate, hate, hate, hate)
Attached Thumbnails
Should I upgrade my original MSPNP?-feed.gif
Joe Perez is offline   Reply With Quote
