Default hissing / grinding noise from m45

so recently i changed out my supercharger belt because it was slipping, squealing madly, and I wasn't getting any boost past 2psi. After the belt swap it sounded find but wasn't getting the full 5-6psi of boost on my gauge. I just thought maybe the belt needs to be broken in a bit more. So I drove around on it for a while then took it to Laguna Seca the day after. At the track I noticed this sound after 1 session.


i have no idea what can be causing it. I tighten down the clamps some more on the couplers...should I tighten it down some more?

When I apply throttle to the car, the sound stays the same. I'll get a video of it asap. Not sure on what to do.

any help would be appreciated. thanks in advance.
kapao818 is offline   Reply With Quote
Old 01-03-2012, 10:16 AM   #2
Elite Member
iTrader: (21)

Join Date: Jun 2007
Location: Rochester, NY
Posts: 5,687
Total Cats: 560
Default

Coupler is shot. You need to open up the nose, replace the coupler and change the oil.
rleete is offline   Reply With Quote
Old 01-03-2012, 11:15 AM   #3
Tour de Franzia
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

Quote:
Originally Posted by rleete View Post
Coupler is shot. You need to open up the nose, replace the coupler and change the oil.
Attached Thumbnails
hissing / grinding noise from m45-hand-dryer-2873.jpg
hustler is offline   Reply With Quote
Old 01-03-2012, 04:17 PM   #4
Destroyer of Inconel
iTrader: (37)

EO2K's Avatar

Join Date: Apr 2010
Location: In ur driveway, abusin' ur WPA
Posts: 9,642
Total Cats: 954
Default

Welcome to the forum! Go make an intro thread before the wolves find you. Be prepared to wade through the abuse re:supercharger around here. Just sayin'

How many miles are on that blower? There are all kinds of bearings and crap inside those things that can go bad. Professional rebuild is not unthinkable. You can contact Magnuson in SoCal and see what they can do for you. They are an authorized Eaton dealer and service/rebuild center and I believe they were the original supplier to Jackson Racing back in the day. I had a M45 rebuild and rotor recoat quoted at around $350 a couple years ago, not sure what it goes for now.

How close are you to Laguna Seca? I live right down the road. You should join up with NorCalUFO and come autoX with us in Marina
EO2K is offline   Reply With Quote
Old 01-04-2012, 03:54 AM   #5
Newb
Thread Starter

Join Date: Jun 2010
Posts: 4
Total Cats: 0
Default

Quote:
Originally Posted by rleete View Post
Coupler is shot. You need to open up the nose, replace the coupler and change the oil.
oh ok. dang i was hoping not to have to change the oil.

Quote:
Originally Posted by hustler View Post
haha in the future!

Quote:
Originally Posted by EO2K View Post
Welcome to the forum! Go make an intro thread before the wolves find you. Be prepared to wade through the abuse re:supercharger around here. Just sayin'

How many miles are on that blower? There are all kinds of bearings and crap inside those things that can go bad. Professional rebuild is not unthinkable. You can contact Magnuson in SoCal and see what they can do for you. They are an authorized Eaton dealer and service/rebuild center and I believe they were the original supplier to Jackson Racing back in the day. I had a M45 rebuild and rotor recoat quoted at around $350 a couple years ago, not sure what it goes for now.

How close are you to Laguna Seca? I live right down the road. You should join up with NorCalUFO and come autoX with us in Marina
not certain on the mileage on the blower. but the PO said he only put 5000 miles on it. will a s/c be damaged with that little miles?

oh thanks for the tip on magnuson. hopefully if i change out the coupler it'll be ok.

i actually live in los angeles. So quite a bit away from laguna seca. i only drove up to norcal for the laguna seca event and to hang out with some of my norcal friends. next time i do go up, i'll give you a PM and hopefully there will be an autox event that's happening at the same time
kapao818 is offline   Reply With Quote
Old 01-04-2012, 10:01 PM   #6
Junior Member
iTrader: (1)

Join Date: Dec 2010
Location: Knoxville, TN
Posts: 279
Total Cats: 2
Default

unless you damaged the unit somehow I would seriously doubt that 5K mile claim
I put 30,000 on an M-45; sold it to another miata nut who has added more miles and no damage
mx594m is offline   Reply With Quote
Old 01-04-2012, 10:24 PM   #7
Elite Member
iTrader: (21)

Join Date: Jun 2007
Location: Rochester, NY
Posts: 5,687
Total Cats: 560
Default

Having belts misaligned (and way too tight) could damage the nose bearings. Once thos go, the coupler is toast.
rleete is offline   Reply With Quote
Old 01-05-2012, 02:13 AM   #8
Newb
Thread Starter

Join Date: Jun 2010
Posts: 4
Total Cats: 0
Default

Quote:
Originally Posted by rleete View Post
Having belts misaligned (and way too tight) could damage the nose bearings. Once thos go, the coupler is toast.
oh ok. i'm going to have to take it into Magnuson soon then to get it checked out. thanks for the advice
kapao818 is offline   Reply With Quote
Old 01-05-2012, 03:23 AM   #9
Elite Member
iTrader: (3)

Join Date: Feb 2008
Location: Huntsville, AL
Posts: 1,882
Total Cats: 45
Default

Call this guy:

http://www.embreemachine.com/


It sounds like nuked bearings to me.
vehicular is offline   Reply With Quote
Old 01-05-2012, 07:13 PM   #10
Elite Member
iTrader: (7)

jeff_man's Avatar

Join Date: May 2007
Location: Dallas, Tx
Posts: 3,056
Total Cats: 103
Default

Quote:
Originally Posted by kapao818 View Post

[url]
You need to pull your charger and open it up and race grease the inside and change the oil and seals.

How it should sound

jeff_man is offline   Reply With Quote
