Default Eccentric locks

https://www.flyinmiata.com/eccentric-lock.html

Has anyone seen or used these before? I did a google search and didn't see anything on MT, but these look interesting.

These are pretty $$ (for 8), but I think it's an interesting side effect that alignments are discretized. Less fine adjustment, but repeatable, which seems cool. What I'd really like to hear is how strong they are.
afm is offline   Reply With Quote
Old 04-08-2016, 11:49 PM   #2
Junior Member
iTrader: (6)

Join Date: Feb 2011
Posts: 421
Total Cats: 9
Default

i have a set im installing tomorrow. i am only putting a pair in the front camber bolts as thats my biggest problem area. they are pretty stout and tolerances are pretty close but not perfect by any means.
Twibs415 is offline   Reply With Quote
Old 04-09-2016, 12:35 AM   #3
afm
Senior Member
Thread Starter
iTrader: (3)

Join Date: Nov 2015
Location: Berkeley, CA
Posts: 583
Total Cats: 59
Default

I just bought enough to do my FLCA eccentrics. Will review after a few track days.
afm is offline   Reply With Quote
Old 04-09-2016, 03:51 AM   #4
Junior Member
iTrader: (2)

Join Date: May 2014
Location: Arlington, TX
Posts: 328
Total Cats: 40
Default

All eccentric fastener joints on our aircraft wing design use a very similar type of eccentric lock. That means these are probably going to solve the issue of the slipping eccentrics.

I'm glad someone made a custom set because the standard off the shelf parts we use cost $$$ and don't come in metric sizes.
Dustin1824 is offline   Reply With Quote
Old 04-09-2016, 08:55 AM   #5
Senior Member
iTrader: (1)

Join Date: Jun 2006
Location: Sweden
Posts: 1,391
Total Cats: 58
Default Eccentric locks

The Holy grail would be reproducible shims.
The problem is the small differences between the nubs on the subframes.
It's a question about making 16 different custom shim sets (or e.g. 8 sided washers).

But if you have experienced a cam bolt loosening in a corner, you would want to prevent it.

$13 does not sound bad at all, or was that each...?
NiklasFalk is offline   Reply With Quote
Old 04-09-2016, 09:16 AM   #6
afm
Senior Member
Thread Starter
iTrader: (3)

Join Date: Nov 2015
Location: Berkeley, CA
Posts: 583
Total Cats: 59
Default

Quote:
Originally Posted by NiklasFalk View Post
$13 does not sound bad at all, or was that each...?
$13 each just for the locks. Just about the prices of adding new camber bolts.
afm is offline   Reply With Quote
Old 04-09-2016, 08:51 PM   #7
Junior Member
iTrader: (6)

Join Date: Feb 2011
Posts: 421
Total Cats: 9
Default

I just installed mine. It was a pain in the ***. There is also some play in the lock to subframe probably .2 of a degree. Tip your alignment guy after having them install these
Twibs415 is offline   Reply With Quote
Old 04-09-2016, 09:52 PM   #8
Senior Member
iTrader: (1)

Join Date: Jul 2012
Location: durham NC
Posts: 767
Total Cats: 115
Default

Is 16 steps enough resolution? Also, I am only seeing 8 positions. Is something offset so it can be flipped to double the number of increments?
asmasm is offline   Reply With Quote
Old 04-09-2016, 09:59 PM   #9
Junior Member
iTrader: (6)

Join Date: Feb 2011
Posts: 421
Total Cats: 9
Default

You can flip the center piece and get the other 8. Again there is a little bit of play once installed. I was able to acheive -3 camber perfectly on both sides. I think it was that these aren't really needed but more so added insurance.
Twibs415 is offline   Reply With Quote
Old 02-23-2017, 11:59 AM   #10
Junior Member
iTrader: (2)

Join Date: Oct 2007
Location: Louisville, KY
Posts: 419
Total Cats: 9
Default

Any update on these? Are they lasting? Any issues?
fourwhls is offline   Reply With Quote
Old 02-23-2017, 12:19 PM   #11
afm
Senior Member
Thread Starter
iTrader: (3)

Join Date: Nov 2015
Location: Berkeley, CA
Posts: 583
Total Cats: 59
Default

No issues. They're a little fiddly to set up, but that comes with the territory.
afm is offline   Reply With Quote
Old 02-23-2017, 11:49 PM   #12
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: NH
Posts: 9,093
Total Cats: 90
Default

I'd rather just use the current method of REEF the **** out of them. Or if you're just running a more normal miata and never change your alignment settings, just tack weld the adjusters in position.
Leafy is offline   Reply With Quote
Old 02-24-2017, 01:18 AM   #13
Mr Broke Pants
iTrader: (9)

thumpetto007's Avatar

Join Date: Sep 2010
Posts: 1,602
Total Cats: 28
Default

^thats what emilio told me to do. The alignment bolts are a wear item because they end up stretching at "tight enough"

Granted I dont race my car, but I've been on very rough roads (like broken concrete) over 1g cornering, and not had any problems. I am guessing I have 1 more alignment out of my current bolts.

Although long term, it would be better to have locking mechanisms, because the alignment bolts arent cheap.
thumpetto007 is offline   Reply With Quote
Old 02-24-2017, 11:44 AM   #14
573
Junior Member
iTrader: (2)

573's Avatar

Join Date: Nov 2011
Location: Troy, Michigan
Posts: 252
Total Cats: 16
Default

I have 8 of them waiting to go on my car before this summer. I had my alignment shift twice on track last year despite having made the bolts pretty damn tight(although to be fair I'd done a few alighenmts with those bolts and they were likely plastically deformed at that point). Missing a session to do a trackside alignment on crooked pavement isn't my idea of fun. I'm really hoping these will allow me to maintain specs without having to make the bolts concerningly tight.
573 is offline   Reply With Quote
