Old 11-30-2016, 02:30 PM   #121
Elite Member

codrus's Avatar

Join Date: Mar 2007
Location: Santa Clara, CA
Posts: 3,658
Total Cats: 319
Default

The big difference between Home Depot Racing spoilers and fancy carbon fiber wings is the downforce to drag ratio.

--Ian
codrus is offline   Reply With Quote
Old 11-30-2016, 02:44 PM   #122
Art
Junior Member

Join Date: Jul 2016
Posts: 194
Total Cats: -91
Default

Yeah I have a great deal of respect for the people that earn a living developing these things. It's just nice to see the home ingenuity.
Art is offline   Reply With Quote
Old 11-30-2016, 04:57 PM   #123
Senior Member
Thread Starter

Join Date: Sep 2015
Location: San Jose, CA
Posts: 993
Total Cats: 29
Default

I would take an actual apr/singular wing over my spoiler and day of the week in a heartbeat. There is no argument that my spoiler is better. But for $30 you can't beat it.
MiataMan00 is offline   Reply With Quote
Old 11-30-2016, 05:26 PM   #124
Moderator
iTrader: (11)

sixshooter's Avatar

Join Date: Nov 2008
Location: Tampa, Florida
Posts: 14,668
Total Cats: 1,346
Default

Spoilers slow the air over the surfaces preceding them, reducing lift. Wings create down force or negative lift. They operate in very different ways.
sixshooter is offline   Reply With Quote
Old 11-30-2016, 06:01 PM   #125
Destroyer of Inconel
iTrader: (37)

EO2K's Avatar

Join Date: Apr 2010
Location: In ur driveway, abusin' ur WPA
Posts: 9,394
Total Cats: 882
Default

Woah, woah, woah! Lets not turn this into a high level aerodynamics discussion, because nobody wants that.
EO2K is offline   Reply With Quote
Old 12-01-2016, 12:00 AM   #126
Senior Member
Thread Starter

Join Date: Sep 2015
Location: San Jose, CA
Posts: 993
Total Cats: 29
Default

Knoowwllagge.
MiataMan00 is offline   Reply With Quote
Old 12-21-2016, 11:06 PM   #127
Senior Member
Thread Starter

Join Date: Sep 2015
Location: San Jose, CA
Posts: 993
Total Cats: 29
Default

So I got myself a few christmas presents.

1. Racing beat 1.125" sway bar with the brace blocks.




2. 949 Racing Endlinks


3. Blackbird Fabworks GT3 roll bar.


I actually went down to SoCal to pick everything up so I got the chance to meet Moti from blackbird and Dan and Sonny from 949 Racing. Super nice people. I could have talked for hours with Sonny about anything miata related. I also got try out the quaife sequential that was in taxi (Not driving just sitting still).

I installed the sway bar and end links today and felt a massive difference in turn in response as well as some reduced body roll. I dint take any pics because its been done 1.3 billion times before.

Roll bar installation will be soon.
MiataMan00 is offline   Reply With Quote
Old 12-22-2016, 06:52 AM   #128
mkturbo.com
iTrader: (24)

shuiend's Avatar

Join Date: May 2006
Location: Charleston SC
Posts: 13,361
Total Cats: 997
Default

The 949 Racing end links are BALLER! They are by far the nicest and easiest I have ever used on a miata.
shuiend is offline   Reply With Quote
Old 12-22-2016, 07:27 PM   #129
Senior Member
Thread Starter

Join Date: Sep 2015
Location: San Jose, CA
Posts: 993
Total Cats: 29
Default

Quote:
Originally Posted by shuiend View Post
The 949 Racing end links are BALLER! They are by far the nicest and easiest I have ever used on a miata.
I quite like them. only took me about 10min to set up.
MiataMan00 is offline   Reply With Quote
Old 12-25-2016, 03:12 AM   #130
Senior Member
Thread Starter

Join Date: Sep 2015
Location: San Jose, CA
Posts: 993
Total Cats: 29
Default

So when I was installing the sway bar I had to remove one of the intercooler couplers. And I saw this....


That is more than a spoon full to put it in perspective. The turbo is relatively new so I have a hard time believing it is the seals. It COULD be that the turbo needs a oil restrictor but nobody else has this issue with the efr turbos so I'm shitting my pants right now.
MiataMan00 is offline   Reply With Quote
Old 12-25-2016, 07:27 AM   #131
SADFab Destructive Testing Engineer
iTrader: (5)

aidandj's Avatar

Join Date: Apr 2014
Location: Beaverton, USA
Posts: 17,434
Total Cats: 1,374
Default

Efrs have built in restrictors. Check the drain line for kinds or blockage.
aidandj is offline   Reply With Quote
Old 12-25-2016, 01:26 PM   #132
Moderator
iTrader: (11)

sixshooter's Avatar

Join Date: Nov 2008
Location: Tampa, Florida
Posts: 14,668
Total Cats: 1,346
Default

Check Ryan_G 's build thread for the same problem on a EFR.
sixshooter is offline   Reply With Quote
Old 12-25-2016, 01:28 PM   #133
Elite Member
iTrader: (8)

Ryan_G's Avatar

Join Date: Jan 2012
Location: Tampa, Florida
Posts: 2,455
Total Cats: 141
Default

How big is your oil drain line? I have found that the 8AN minimum recommendation is not adequate. It needs to be at least 10AN or 5/8".
Ryan_G is offline   Reply With Quote
Old 12-25-2016, 01:33 PM   #134
Moderator
iTrader: (11)

sixshooter's Avatar

Join Date: Nov 2008
Location: Tampa, Florida
Posts: 14,668
Total Cats: 1,346
Default

Tell him about using a threaded fitting in the drain hole. Do you have any pictures from the analysis they did talking about the fitting?
sixshooter is offline   Reply With Quote
Old 12-25-2016, 01:37 PM   #135
SADFab Destructive Testing Engineer
iTrader: (5)

aidandj's Avatar

Join Date: Apr 2014
Location: Beaverton, USA
Posts: 17,434
Total Cats: 1,374
Default

He has a TSE kit. Which uses a flange fitting and 10AN lines.
aidandj is offline   Reply With Quote
Old 12-25-2016, 01:39 PM   #136
Elite Member
iTrader: (8)

Ryan_G's Avatar

Join Date: Jan 2012
Location: Tampa, Florida
Posts: 2,455
Total Cats: 141
Default

Quote:
Originally Posted by sixshooter View Post
Tell him about using a threaded fitting in the drain hole. Do you have any pictures from the analysis they did talking about the fitting?
Ah yes. I had my turbo serviced by a Borg Warner master distributor for this issue. It was under warranty. They said the seals were fine but the oil drain was too small and the oil drain fitting protruded too much into the housing requiring the oil to pool up prior to draining. The technician suggested using a flanged fitting that does not thread into the NPT bung.
Ryan_G is offline   Reply With Quote
Old 12-25-2016, 02:38 PM   #137
Senior Member
Thread Starter

Join Date: Sep 2015
Location: San Jose, CA
Posts: 993
Total Cats: 29
Default

Quote:
Originally Posted by aidandj View Post
He has a TSE kit. Which uses a flange fitting and 10AN lines.
This. The oil drain is massive. So I don't think it is kinked or clogged. It just seems to huge to cause any issue.

Paging Savington.

Last edited by MiataMan00; 12-25-2016 at 02:48 PM.
MiataMan00 is offline   Reply With Quote
Old 12-25-2016, 02:47 PM   #138
Moderator
iTrader: (11)

sixshooter's Avatar

Join Date: Nov 2008
Location: Tampa, Florida
Posts: 14,668
Total Cats: 1,346
Default

Well, that's probably not the problem then. Just seemed like a good thing to check.
sixshooter is offline   Reply With Quote
Old 12-25-2016, 03:48 PM   #139
SADFab Destructive Testing Engineer
iTrader: (5)

aidandj's Avatar

Join Date: Apr 2014
Location: Beaverton, USA
Posts: 17,434
Total Cats: 1,374
Default

Do you have shaft play?
aidandj is offline   Reply With Quote
Old 12-25-2016, 04:10 PM   #140
Senior Member
Thread Starter

Join Date: Sep 2015
Location: San Jose, CA
Posts: 993
Total Cats: 29
Default

Quote:
Originally Posted by aidandj View Post
Do you have shaft play?
No not in the slightest bit.
MiataMan00 is offline   Reply With Quote
