Old 02-18-2013, 01:56 AM   #21
Tour de Franzia
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

I would not coat the inside, too much risk of it flaking.
hustler is offline   Reply With Quote
Old 02-18-2013, 09:39 AM   #22
Senior Member
Thread Starter

Join Date: Feb 2009
Location: Philadelphia
Posts: 815
Total Cats: 47
Default

Thats what I was worried about too. So what do I do for the inners? Moisture collects there, no? Especially since I am doing topmount so the runners all dip down, and go 180* up? I just wanna tske every precaution I can as I did when I built the motor (thanks for everyones help on that btw)
Mazdaspeeder is offline   Reply With Quote
Old 02-18-2013, 09:46 AM   #23
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: NH
Posts: 9,092
Total Cats: 90
Default

You either dont worry about the rust, or go stainless, which will still rust, just not as bad.
Leafy is offline   Reply With Quote
Old 02-18-2013, 11:38 AM   #24
y8s
2 Props,3 Dildos,& 1 Cat
iTrader: (8)

y8s's Avatar

Join Date: Jun 2005
Location: Fake Virginia
Posts: 19,038
Total Cats: 407
Default

Here's 8 years and 40k+ miles.

sorry it's not a better shot, but you can see the #1 runner at the head. The coating is the silvery jet hot style. It's held up pretty well for its age and miles.

Attached Thumbnails
Mild vs Stainless manifolds-dsc_5613.jpg
y8s is offline   Reply With Quote
Old 02-18-2013, 11:55 AM   #25
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,872
Total Cats: 1,790
Default

I'll buy a motor/chasis where people dont have these crazy cracked manifold issues, and run SS 304.
Braineack is offline   Reply With Quote
Old 02-18-2013, 02:08 PM   #26
NB/VVT Connoisseur
iTrader: (23)

viperormiata's Avatar

Join Date: Aug 2008
Location: Key West
Posts: 6,071
Total Cats: 253
Default

Quote:
Originally Posted by Braineack View Post
I'll buy a motor/chasis where people dont have these crazy cracked manifold issues, and run SS 304.
Tractor ***** engines
viperormiata is offline   Reply With Quote
Old 02-19-2013, 10:07 AM   #27
Senior Member
Thread Starter

Join Date: Feb 2009
Location: Philadelphia
Posts: 815
Total Cats: 47
Default

y8s, did you coat the inside? Did anyone? Or am I thinking into this rust thing too deep
Mazdaspeeder is offline   Reply With Quote
Old 02-19-2013, 10:17 AM   #28
y8s
2 Props,3 Dildos,& 1 Cat
iTrader: (8)

y8s's Avatar

Join Date: Jun 2005
Location: Fake Virginia
Posts: 19,038
Total Cats: 407
Default

nobody coats the inside for the reason hustler said.
y8s is offline   Reply With Quote
Old 02-19-2013, 10:33 AM   #29
Senior Member
iTrader: (2)

Join Date: Jan 2010
Location: Denver
Posts: 909
Total Cats: 14
Default

The white lightning coating is for the outside only it is not a smooth coating it has a slightly rough texture. Never coat the inside of your manifold, unless you want to risk nasty stuff going thru the turbine. I have a few pics of my swain tech WL coated manifold in my build thread.
https://www.miataturbo.net/build-thr...version-42810/
hingstonwm is offline   Reply With Quote
Old 02-20-2013, 03:54 AM   #30
Junior Member
iTrader: (1)

Join Date: Dec 2010
Location: California
Posts: 53
Total Cats: 15
Default

I would suggest using mild steel on the manifold and then coating it with a type of HVOF thermal spray such as SwainTech White Lightening, Jet Hot 2000/2500, or Zircotec. The HVOF process actually embeds ceramic media into the surface of the metal.

The advantage of a properly coated manifold are reduced underhood temperatures and faster turbo spool. The silver "ceramic" coatings that you most commonly see are paints that generally have poor insulting qualities and will not survive on a turbo manifold.

If you insist on having a Stainless Steel manifold I would suggest using 321 stainless or Inconel. 304 stainless is not a good material choice in my opinion.
crowder92 is offline   Reply With Quote
Old 02-20-2013, 04:25 AM   #31
Senior Member
iTrader: (14)

Join Date: Oct 2006
Location: Las Cruces, NM
Posts: 1,403
Total Cats: 262
Default

I probably have the first equal length EFR manifold from Artech. I went with mild steel due to the fact that Abe warranties the mild stainless longer than the SS and that you don't need a crane for it. As long as you coat it properly, it should last.
99mx5 is offline   Reply With Quote
Old 02-20-2013, 09:40 AM   #32
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,872
Total Cats: 1,790
Default

I care more about coating for the thermal conductiveness advantage, not "lasting as long."
Braineack is offline   Reply With Quote
Old 02-20-2013, 09:52 AM   #33
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: NH
Posts: 9,092
Total Cats: 90
Default

Quote:
Originally Posted by crowder92 View Post
I would suggest using mild steel on the manifold and then coating it with a type of HVOF thermal spray such as SwainTech White Lightening, Jet Hot 2000/2500, or Zircotec. The HVOF process actually embeds ceramic media into the surface of the metal. Zircotec Performance White Ceramic Exhaust Manifold Coating Process - YouTube

The advantage of a properly coated manifold are reduced underhood temperatures and faster turbo spool. The silver "ceramic" coatings that you most commonly see are paints that generally have poor insulting qualities and will not survive on a turbo manifold.

If you insist on having a Stainless Steel manifold I would suggest using 321 stainless or Inconel. 304 stainless is not a good material choice in my opinion.
Is Jet Hot a true ceramic? I was under the impression that it was the shiny type.

I can see where you're coming from with the 321 stainless or the inconel, if you're making a thin wall manifold in 16 or 18ga, but even 316Ti would be passable. 304 should still be sufficient even though it lacks the high temp strength advantages that 321 and nickle alloys have over carbon steel. Its very easy to get a clean weld bead (especially 304L) to minimize the likelyhood of a fatigue failure starting in a weld crack, its significantly cheaper, and has been used successfully over and over again in turbo manifolds. I think the crux of getting a 304 manifold to last it making the runners similarly shaped enough that its not trying to tear itself apart when its heated, and figuring out how to support the weight of the turbo while still allowing it to move around as the manifold changes temperature.
Leafy is offline   Reply With Quote
Old 02-20-2013, 02:05 PM   #34
Senior Member
Thread Starter

Join Date: Feb 2009
Location: Philadelphia
Posts: 815
Total Cats: 47
Default

Quote:
Originally Posted by 99mx5 View Post
I probably have the first equal length EFR manifold from Artech. I went with mild steel due to the fact that Abe warranties the mild stainless longer than the SS and that you don't need a crane for it. As long as you coat it properly, it should last.
I actually used your build for a lot of information for my own. Ive seen vids of your car too. AriM on youtube right? How do you like the setup?
Mazdaspeeder is offline   Reply With Quote
Old 02-20-2013, 02:13 PM   #35
Senior Member
iTrader: (14)

Join Date: Oct 2006
Location: Las Cruces, NM
Posts: 1,403
Total Cats: 262
Default

Yup, that's me. I'm loving it!
99mx5 is offline   Reply With Quote
Old 02-20-2013, 05:04 PM   #36
y8s
2 Props,3 Dildos,& 1 Cat
iTrader: (8)

y8s's Avatar

Join Date: Jun 2005
Location: Fake Virginia
Posts: 19,038
Total Cats: 407
Default

Quote:
Originally Posted by 99mx5 View Post
Abe warranties the mild stainless longer than the SS
why in the world would he ever do that.
y8s is offline   Reply With Quote
Old 02-20-2013, 09:02 PM   #37
Elite Member

Join Date: Apr 2010
Location: Newcastle, Australia
Posts: 2,639
Total Cats: 25
Default

Takes much longer to rust through 1/4" of mild than put a crack in stainless, or warp the hell out of it.

Dann
