Old 02-15-2008, 10:32 AM   #21
Elite Member
iTrader: (15)

Join Date: Dec 2007
Location: San Antonio, Texas
Posts: 4,889
Total Cats: 28
Default

Awesome I have been looking for something like this.

Quote:
Originally Posted by TurboTim View Post
I can get it for you or any place that sells thermotec (jegs, summit, etc). I bend it with my fingers and cut it with tin snips. It works incredibly well for such thin aluminum, must be the louvers. After a hard run I can place my hand directly behind it (where the dip stick and heater core hoses are) and feel fine while my upper arm and face feel like it's melding.

http://www.thermotec.com/product_detail.php?prd_id=28
ZX-Tex is offline   Reply With Quote
Old 02-15-2008, 10:37 AM   #22
Elite Member
iTrader: (39)

Zabac's Avatar

Join Date: Sep 2007
Location: High Point NC
Posts: 4,854
Total Cats: 8
Default

sweet, only you would do something this cool man
cant wait to see dyno diff. b/w this set up and old one...i suspect faster spool and 7% in power across the entire band
Zabac is offline   Reply With Quote
Old 02-15-2008, 10:45 AM   #23
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,860
Total Cats: 1,788
Default

Quote:
Originally Posted by whaaamx5 View Post
sweet, only you would do something this cool man
cant wait to see dyno diff. b/w this set up and old one...i suspect faster spool and 7% in power across the entire band
why do you expect faster spool and 7% power increase?
Braineack is offline   Reply With Quote
Old 02-15-2008, 10:47 AM   #24
Ben
Supporting Vendor
iTrader: (33)

Ben's Avatar

Join Date: Jul 2006
Location: atlanta-ish
Posts: 12,689
Total Cats: 99
Default

Damn good work. As always.
Ben is offline   Reply With Quote
Old 02-15-2008, 10:53 AM   #25
Elite Member
Thread Starter
iTrader: (9)

TurboTim's Avatar

Join Date: Jun 2006
Location: Chesterfield, NJ
Posts: 6,484
Total Cats: 248
Default

Quote:
Originally Posted by Braineack View Post
smaller turbines, but much larger trim. what you might loose 100-200rpm of spool

What i like is that, by my math, you put out 15 lb/min at redline through the exhaust...so about 7.5 lb/min each....the 1544's efficiency max was at 6.3 lb/min, the 1548's are at 8 lb/min....so they should make better hp per psi.

they do look physically bigger in there...how long before two 2056s?
The exhaust sides (x2) should flow around the 2560's, while the compreser flows...a lot. I'm a little worried it my flow too much.

Now that the manifold has T2 flanges, all that needs to be redone is the downpipe. Unfortuantely that's the hardest part. With these turbos the downpipe covered one bolt hole so we had to drill a hole and weld a tube thru the downpipe and use a ~3" long bolt.

I should have layed the 2871 in there to see if it fit.
TurboTim is offline   Reply With Quote
Old 02-15-2008, 10:55 AM   #26
Elite Member
Thread Starter
iTrader: (9)

TurboTim's Avatar

Join Date: Jun 2006
Location: Chesterfield, NJ
Posts: 6,484
Total Cats: 248
Default

Quote:
Originally Posted by whaaamx5 View Post
sweet, only you would do something this cool man
cant wait to see dyno diff. b/w this set up and old one...i suspect faster spool and 7% in power across the entire band
Hmm. I think slower spool, and I hope for more than 7%.

If spool is too slow I can always turn the anti lag back on
TurboTim is offline   Reply With Quote
Old 02-15-2008, 11:03 AM   #27
Elite Member
iTrader: (39)

Zabac's Avatar

Join Date: Sep 2007
Location: High Point NC
Posts: 4,854
Total Cats: 8
Default

Quote:
Originally Posted by Braineack View Post
why do you expect faster spool and 7% power increase?
pretty much lol
a little guesstimategage
Zabac is offline   Reply With Quote
Old 02-15-2008, 11:22 AM   #28
Senior Member
iTrader: (2)

Join Date: Aug 2007
Location: North Cackalackey
Posts: 716
Total Cats: 2
Default

glad to see you are doing it again. what can i say it takes lots of skill to attempt something like this. Great job.
musanovic is offline   Reply With Quote
