Default Clutch Master Cylinder suggestions

A little background:
I've had 3 clutch master cylinders fail on me in the past 3 years. The first was presumably stock, and the others were O'Reilly parts (PowerTorque I think is the brand name) which are complete crap. They have this particular rubber piece which disintegrates and contaminates the hydraulic fluid. Here's a pic of the fluid that I flushed that had been in there for about 7 months:

The fluid then clogged and killed my slave last time, too. The PowerTorque has a lifetime warranty, but I really don't want to have to replace my master cylinder every <1 year.
It looks like my options are:
Replace it every year (free, except time and annoyance)
Buy a quality aftermarket one (?)
Go OEM (~$120).

What brands of master cylinders have you had good luck with, and for how long?
Attached Thumbnails
Clutch Master Cylinder suggestions-1titvhz.jpg

Last edited by Morshu; 03-14-2013 at 01:06 AM.
Morshu is offline   Reply With Quote
Old 03-13-2013, 04:57 PM   #2
Elite Member
iTrader: (21)

Join Date: Jun 2007
Location: Rochester, NY
Posts: 5,685
Total Cats: 557
Default

I used whatever AdvanceAuto had in stock. No problems whatsoever. Cost right around $25.

I also use store brand brake fluid.
rleete is offline   Reply With Quote
Old 03-13-2013, 04:58 PM   #3
Junior Member
Thread Starter

Join Date: Nov 2012
Location: SF Bay Area
Posts: 59
Total Cats: 0
Default

How long has it lasted?
Morshu is offline   Reply With Quote
Old 03-13-2013, 05:03 PM   #4
Elite Member
iTrader: (21)

Join Date: Jun 2007
Location: Rochester, NY
Posts: 5,685
Total Cats: 557
Default

So far, three (almost 4) years. Not a lot of miles (8K?), the car sits all winter. Same for the slave. I replaced the master when the slave went out.

Did you install the parts dry? A small chip or tear on the edge of a seal will cause it to deteriorate quickly. Slather the parts in fluid and don't force anything. It should slip together easily.
rleete is offline   Reply With Quote
Old 03-13-2013, 05:13 PM   #5
Junior Member
Thread Starter

Join Date: Nov 2012
Location: SF Bay Area
Posts: 59
Total Cats: 0
Default

I didn't bench bleed the master before installation, if that's what you're asking. I just removed the old one, installed the new one, filled the reservoir and began to bleed it.
Morshu is offline   Reply With Quote
Old 03-13-2013, 05:46 PM   #6
Elite Member
iTrader: (5)

Join Date: Aug 2011
Location: South Jersey
Posts: 1,523
Total Cats: 30
Default

I've had the advance auto $21 clutch master cylinder for about a month now with no problems.... Not that a month means anything. Hope I get 4 years out of this one like rleet did lol
BTMiata is offline   Reply With Quote
Old 03-13-2013, 07:22 PM   #7
Newb

Join Date: Apr 2010
Location: Dallas Texas
Posts: 30
Total Cats: 0
Default

I swapped mine out with a Doorman one from Rockauto. It's been great for two, possibly three years.

But the paint is crap, so hit it with some cheap spray paint or even the aerosol truck bedliner.
chewy is offline   Reply With Quote
Old 03-13-2013, 11:12 PM   #8
Tour de Franzia
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

I have great luck with the Brake Best brand from O'Reilly.
hustler is offline   Reply With Quote
Old 06-09-2013, 09:25 PM   #9
Junior Member

Join Date: May 2013
Location: In a van by the river
Posts: 49
Total Cats: -31
Default

I just replaced the master with one from Advanced Auto. I highly recommend replacing the lines with a one piece stainless line from Miata Roadster. Very simple and a much better design. The $50 wasn't a factor for me and I highly recommend it.
TurboNA is offline   Reply With Quote
Old 06-10-2013, 06:02 AM   #10
Junior Member
iTrader: (2)

Join Date: Dec 2009
Location: scranton, pa
Posts: 103
Total Cats: 4
Default

most of my replacements are A1 cardone brand. never any issues.

what type of fluid are you using? brand, dot#?
zipstrips is offline   Reply With Quote
Old 06-10-2013, 09:43 AM   #11
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: NH
Posts: 9,092
Total Cats: 90
Default

Does no one sell a rebuild kit with good seals for these things? Rebuilding a master that doesnt have a scored bore is normally super easy and painless.
Leafy is offline   Reply With Quote
Old 06-24-2017, 11:56 AM   #12
Elite Member
iTrader: (17)

Join Date: Aug 2007
Location: Fort Myers, FL
Posts: 2,791
Total Cats: 130
Default

Bump for this ancient thread. Just wanted to see if there are any better options out there.

My clutch master went out so I bought a "OEM Exedy" that lasted 8 days and almost 30 miles. Bought an Advance Auto CMC to replace it and it didn't work at all, exchanged it for another one and after 10 pumps it'll build enough pressure to get the car in gear. If you hold the clutch in pressure only lasts about 2 seconds before the clutch starts to re-engage itself. I feel like there's got to be a better option out there somewhere. These cheap masters just don't seem to handle a stiff clutch, I feel like there's got to be a better option out there.
pdexta is offline   Reply With Quote
Old 06-24-2017, 12:15 PM   #13
Elite Member
iTrader: (3)

concealer404's Avatar

Join Date: Aug 2011
Posts: 8,465
Total Cats: 782
Default

If the master goes out enough to fail completely, it takes the slave with it. And vice versa.

If either FAILS, replace both.

That said, i haven't found one that lasts worth a damn in any Mazda with an aftermarket clutch. Doesn't matter if i'm buying the cheapest one i can find on Rockauto, or paying Emilio for the Exedy units that Rockauto also sells. I have a harder time with slave cylinders. I put a new one on my car every year, new master every two years. The MX6 used to get a new one every oil change.
concealer404 is offline   Reply With Quote
