Old 07-04-2012, 07:05 PM   #141
Junior Member
iTrader: (4)

Join Date: Jan 2009
Location: Fife, Scotland
Posts: 297
Total Cats: 5
Default

Love love love this car
GrahamC is offline   Reply With Quote
Old 07-08-2012, 05:59 PM   #142
Junior Member
Thread Starter

Join Date: Jun 2005
Posts: 175
Total Cats: 17
Default



extremly wet trackday.. 5th gear would spin to 190kph down the back straight..
nooo traction in the corners ended up being more a day to learn how to handle the car in wet conditions, than actually setting decent laptimes.. but it looks cool
Attached Thumbnails
HF-mx5t's 3076 turboed trackday/street toy :)-287811_342765229134470_1328665172_o.jpg
hf-mx5t is offline   Reply With Quote
Old 07-14-2012, 02:31 PM   #143
Junior Member
Thread Starter

Join Date: Jun 2005
Posts: 175
Total Cats: 17
Default



video from that very wet trackday.. not really pushing it as i am unfamiliar with this car on that track, and the rain on my first day doesnt help. my friends mk3 mr2 has a 255whp turbo engine, big brakes, R comp tires,cage+++ both of us are just playing around because of the shitty conditions.
hf-mx5t is offline   Reply With Quote
Old 07-20-2012, 07:18 PM   #144
Junior Member
Thread Starter

Join Date: Jun 2005
Posts: 175
Total Cats: 17
Default



the turbo didnt like last years cracked engine block and water/oil mix..

Have to change the chra :P
hf-mx5t is offline   Reply With Quote
Old 06-09-2014, 06:00 PM   #145
Junior Member
Thread Starter

Join Date: Jun 2005
Posts: 175
Total Cats: 17
Default

there seems to be a strange sound in my car..

ive joined the statistics and broken a 6speed.. 4th gear shattered like glass while rolling on the throttle on the highway.. @2bar boost on the gt3076 so it had some power behind it.

hf-mx5t is offline   Reply With Quote
Old 06-09-2014, 06:27 PM   #146
Senior Member

Join Date: Dec 2004
Location: Brisbane, Australia
Posts: 1,275
Total Cats: 33
Default

Sucks about the gearbox, but nicely done!

I don't want to join that club at the moment!!
timk is offline   Reply With Quote
Old 09-05-2014, 04:01 PM   #147
Junior Member

Join Date: Jan 2007
Posts: 223
Total Cats: 15
Default

Any updates? Did you go Quaife? Or trying another 6-speed? Love the all that ducting. Gave me some good ideas. Thanks.
freedomgli is offline   Reply With Quote
Old 11-15-2014, 05:30 AM   #148
Junior Member
Thread Starter

Join Date: Jun 2005
Posts: 175
Total Cats: 17
Default

strapped in another 6speed.

did a few adjustments to brake bias, boostpressure controlled by TPS value etc and was able to improve my laptimes a bit too.
hf-mx5t is offline   Reply With Quote
Old 11-15-2014, 07:00 AM   #149
Moderator
iTrader: (11)

sixshooter's Avatar

Join Date: Nov 2008
Location: Tampa, Florida
Posts: 16,572
Total Cats: 1,777
Default

30psi on a 3076? Nice.

I'm going to need to step up my game. If this is on pump gas (yes, I know there are differences between countries), I would really like to see your spark map.
sixshooter is online now   Reply With Quote
Old 11-15-2014, 07:25 PM   #150
Junior Member
Thread Starter

Join Date: Jun 2005
Posts: 175
Total Cats: 17
Default

98 octane(ron i guess) , im down at 13-14degrees at 2 bar boost.
it was an absolute monster at 2 bar boost. not sure what the hp/tq figures would be, but somewhere north of 450whp, and a shitload of torque
hf-mx5t is offline   Reply With Quote
Old 11-16-2014, 06:44 AM   #151
Moderator
iTrader: (11)

sixshooter's Avatar

Join Date: Nov 2008
Location: Tampa, Florida
Posts: 16,572
Total Cats: 1,777
Default

What are you limiting the boost to when on the track?
sixshooter is online now   Reply With Quote
Old 11-16-2014, 01:42 PM   #152
Junior Member
Thread Starter

Join Date: Jun 2005
Posts: 175
Total Cats: 17
Default

limited to 1.6 bar for all kinds of use after the 6speed broke. that around 400whp,450nm(at wheels).

Thinking of keeping 1.6 bar for 1st-4th gear, and going back to 2 bar for 5th gear which is the highest gear i will be using on the local tracks with short straights. It should juuust about reach the limiter in 5th with a small power increase from 400whp
hf-mx5t is offline   Reply With Quote
Old 02-02-2018, 10:58 AM   #153
Junior Member
Thread Starter

Join Date: Jun 2005
Posts: 175
Total Cats: 17
Default

small update.. car has been running the last few years with no real big issues. between 25-30k km since my last post, engine is untouched and still running 400+ whp street and some track use

Treated the car to xidas, and some other small upgrades and upgrading the interior etc this winter.

heres a small video from some very mild laps on track, it still moves even when im not pushing

hf-mx5t is offline   Reply With Quote
Old 03-01-2018, 05:53 PM   #154
Junior Member
Thread Starter

Join Date: Jun 2005
Posts: 175
Total Cats: 17
Default

Fixing up the car a bit this winter. fixed rust on the rear of the sills. redoing the interior, installing a mini dashlogger etc. Engine will be pretty much the same.
Upgrading the swaybars, and going to 900lb front springs too..

mini dash is a PLEX usdm 102 pro. it will comunicate with my autronic SM4 ecu using rs232, and has 4 additional analog inputs and 2 egt probe inputs, and supports canbus devices, full logging, smart waring screens with selectable warning levels for most channels++ really cool piece of kit that lets me remove all normal gauges, and still have a streetable car with all info easy to read.
hf-mx5t is offline   Reply With Quote
Old 03-02-2018, 10:39 PM   #155
Elite Member
iTrader: (2)

Mobius's Avatar

Join Date: May 2008
Location: Portland, Oregon
Posts: 3,358
Total Cats: 307
Default

Nice.
Mobius is offline   Reply With Quote
Old 03-29-2018, 12:43 PM   #156
Junior Member
Thread Starter

Join Date: Jun 2005
Posts: 175
Total Cats: 17
Default

Changed my damaged koyo for a supermiata radiator. Made a New mounting plate/shroud for the fans. Made a coolant setup for the wg since it's prepped for that.
Also installing fuel and oil pressure sensors connected to the ecu for failsafes, and a speed sensor for gear dependent boost if i want it.





hf-mx5t is offline   Reply With Quote
