Default Another spool thread - boost rise time at 4000 RPM

Choose a gear so that car is between 65 and 70 mph at 4000 RPM.
Cruise at just above 4000 RPM, coast down to 4000, then floor it.

The data should look like this:

Setting 0 time to be whatever time it hits 100 kPa, here is sample data format (not actual)

5 psi - 0.2 sec
10 psi - 0.5 sec
12 psi - 0.6 sec
15 psi - 0.8 sec
JasonC SBB is offline   Reply With Quote
Old 09-12-2011, 09:22 PM   #2
Elite Member
iTrader: (3)

Join Date: Mar 2008
Location: Granbury, TX
Posts: 6,009
Total Cats: 583
Default

Jason, are you asking us to submit measurements?
hornetball is online now   Reply With Quote
Old 09-12-2011, 09:42 PM   #3
Elite Member
iTrader: (6)

blaen99's Avatar

Join Date: Sep 2010
Location: Seattle, WA
Posts: 4,112
Total Cats: 27
Default

InB4Throttle Response thread!
blaen99 is offline   Reply With Quote
Old 09-12-2011, 10:00 PM   #4
I'm Miserable!
iTrader: (11)

Join Date: Apr 2008
Location: Texas, 'Murica
Posts: 2,505
Total Cats: 7
Default

Please cross post at m.net. I am in for some actual good data though.
chicksdigmiatas is offline   Reply With Quote
Old 09-13-2011, 03:16 AM   #5
Elite Member
Thread Starter

Join Date: Jul 2005
Posts: 6,454
Total Cats: 80
Default

Well maybe the data presented this way is more useful.
Boost appears to be a linear rise; it overshoots 15 psi slightly so it's pretty linear to 15 psi.

0-15 psi time:

4000 RPM - 0.58 sec ~68 mph
4400 RPM - 0.48 sec (same gear)
5000 RPM - 0.42 sec
JasonC SBB is offline   Reply With Quote
Old 09-13-2011, 09:55 PM   #6
I'm Miserable!

Join Date: Jun 2009
Location: albany, ga
Posts: 1,869
Total Cats: 3
Default

You should its a linear rise? seems to me it would start rising quicker and quicker, anyways I got some data I will post up
Techsalvager is offline   Reply With Quote
Old 09-13-2011, 10:01 PM   #7
I'm Miserable!

Join Date: Jun 2009
Location: albany, ga
Posts: 1,869
Total Cats: 3
Default

Pull #1

Map rpm time
102 3788 3.278
110 3906 3.532
130 4150 3.96
160 4361 4.337
187 4577 4.614
205 4712 4.865

Pull #2
Techsalvager is offline   Reply With Quote
Old 01-06-2012, 04:21 AM   #8
Elite Member
Thread Starter

Join Date: Jul 2005
Posts: 6,454
Total Cats: 80
Default

Quote:
Originally Posted by JasonC SBB View Post
Well maybe the data presented this way is more useful.
Boost appears to be a linear rise; it overshoots 15 psi slightly so it's pretty linear to 15 psi.

0-15 psi time:

4000 RPM - 0.58 sec ~68 mph
4400 RPM - 0.48 sec (same gear)
5000 RPM - 0.42 sec
I fixed my loose wastegate and it made a big difference in my 4000 RPM data:

4000 RPM - 0.46 sec
JasonC SBB is offline   Reply With Quote
Old 01-06-2012, 10:42 AM   #9
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

VVT, your boost control system, wastegate spring, and timing will affect the results
Faeflora is offline   Reply With Quote
Old 01-06-2012, 10:54 AM   #10
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 36,186
Total Cats: 2,582
Default

0-21psi in just over .5 seconds.
....not a miata though
18psi is offline   Reply With Quote
Old 01-06-2012, 12:24 PM   #11
I'm Miserable!

Join Date: Dec 2011
Posts: 346
Total Cats: -223
Default

Wont this thread be a little biased depending on turbo and displacement?
Boost Joose is offline   Reply With Quote
Old 01-06-2012, 12:28 PM   #12
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 36,186
Total Cats: 2,582
Default

So run a gt2554 on a 3 Liter I6 and win this thread then
18psi is offline   Reply With Quote
Old 01-06-2012, 12:35 PM   #13
I'm Miserable!

Join Date: Dec 2011
Posts: 346
Total Cats: -223
Default

Wow, that would really throw this thread for a loop. I was thinking displacement ranging from 1.6-2.1L not 1.6-7.0......and just to make sure this thread is basically a dick measuring contest, correct? lol Not really relevant except for initial spool for highway racing?
Boost Joose is offline   Reply With Quote
Old 01-06-2012, 12:39 PM   #14
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

Quote:
Originally Posted by JasonC SBB View Post
Well maybe the data presented this way is more useful.
Boost appears to be a linear rise; it overshoots 15 psi slightly so it's pretty linear to 15 psi.

0-15 psi time:

4000 RPM - 0.58 sec ~68 mph
4400 RPM - 0.48 sec (same gear)
5000 RPM - 0.42 sec
Boost definitely DOES NOT always rise linearly. It depends on the turbo, mani, flow of the motor it's attached to, wastegate, timing....
Faeflora is offline   Reply With Quote
Old 01-06-2012, 12:42 PM   #15
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 36,186
Total Cats: 2,582
Default

Quote:
Originally Posted by Boost Joose View Post
Wow, that would really throw this thread for a loop. I was thinking displacement ranging from 1.6-2.1L not 1.6-7.0......and just to make sure this thread is basically a dick measuring contest, correct? lol Not really relevant except for initial spool for highway racing?

To a noob like you, yes.
To others, like Jason, no.

If you read through our previous spool thread and glance over the plotted charts with everyones contributed info, you'll find it very helpful since you will see what combo's produce what curves.

Post less.
Read more.
18psi is offline   Reply With Quote
Old 01-06-2012, 12:42 PM   #16
NB/VVT Connoisseur
iTrader: (23)

viperormiata's Avatar

Join Date: Aug 2008
Location: Key West
Posts: 6,071
Total Cats: 253
Default

Quote:
Originally Posted by Boost Joose View Post
Wow, that would really throw this thread for a loop. I was thinking displacement ranging from 1.6-2.1L not 1.6-7.0......and just to make sure this thread is basically a dick measuring contest, correct? lol Not really relevant except for initial spool for highway racing?
My dick is bigger than yours.

Attached Thumbnails
Another spool thread - boost rise time at 4000 RPM-imag0197.jpg
viperormiata is offline   Reply With Quote
Old 01-06-2012, 12:45 PM   #17
meatbag
iTrader: (50)

gospeed81's Avatar

Join Date: Nov 2008
Location: Houston, TX
Posts: 7,357
Total Cats: 26
Default

Quote:
Originally Posted by 18psi View Post
Post less.
Read more.
I tried to help him with this issue earlier...but some ******** keeps unbanning him.
gospeed81 is offline   Reply With Quote
Old 01-06-2012, 02:04 PM   #18
Elite Member
Thread Starter

Join Date: Jul 2005
Posts: 6,454
Total Cats: 80
Default

Quote:
Originally Posted by Faeflora View Post
Boost definitely DOES NOT always rise linearly. It depends on the turbo, mani, flow of the motor it's attached to, wastegate, timing....
In the case of the data I took above, it's pretty damn linear.
JasonC SBB is offline   Reply With Quote
Old 01-06-2012, 02:08 PM   #19
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 36,186
Total Cats: 2,582
Default

Yes, but in many other cases, he's right imo
18psi is offline   Reply With Quote
Old 01-06-2012, 03:04 PM   #20
Elite Member
Thread Starter

Join Date: Jul 2005
Posts: 6,454
Total Cats: 80
Default

Agreed, I was talking about my particular data set.
JasonC SBB is offline   Reply With Quote
