Old 07-17-2013, 05:06 PM   #81
NB/VVT Connoisseur
iTrader: (23)

viperormiata's Avatar

Join Date: Aug 2008
Location: Key West
Posts: 6,069
Total Cats: 253
Default

................what the **** did I just read?

Attached Thumbnails
Compound boost: EFR 7670 into Coldside FFS W/ H20/Meth into 10.5:1 VVT Built Engine-f01.gif
viperormiata is offline   Reply With Quote
Old 07-17-2013, 06:31 PM   #82
Elite Member
Thread Starter
iTrader: (15)

patsmx5's Avatar

Join Date: Aug 2007
Location: Houston, TX
Posts: 8,796
Total Cats: 248
Default

Quote:
Originally Posted by soviet View Post
my god, you are so much dumber than I thought.
enjoy your pile of ****.
???
patsmx5 is offline   Reply With Quote
Old 07-17-2013, 06:42 PM   #83
Senior Member
iTrader: (2)

Join Date: Nov 2007
Location: Saint Paul, MN
Posts: 1,295
Total Cats: 22
Default

Your car will never make the numbers you want, especially at 9:1 afr. I made 190hp at 9-10:1 and leaned it out and advanced timing some and now I make 280-300 depending on boost. Running it rich will just end up building up huge amounts of carbon deposits.
Der_Idiot is offline   Reply With Quote
Old 07-17-2013, 06:47 PM   #84
Elite Member
iTrader: (3)

concealer404's Avatar

Join Date: Aug 2011
Posts: 8,460
Total Cats: 782
Default

Quote:
Originally Posted by nitrodann View Post
I intend to do this with a toyota SC14 and something big and cheap (T04 or something).

The sc14 will be mounted below the turbo, allowing intercooling of both, I also intend to spray before the blower.

SC14 also has a bypass for experimenting with it. Although I know an SC14 can do 400whp on the right setup on its own, so I dont see it becoming a restriction unless I went for the ultimate record.

Dann

... on what?

An LSx that made 400whp n/a?


Or are we talking about magical upside-down dynos again?
concealer404 is offline   Reply With Quote
Old 07-17-2013, 06:54 PM   #85
Elite Member
iTrader: (10)

soviet's Avatar

Join Date: Jan 2010
Location: VA
Posts: 3,517
Total Cats: 256
Default

Quote:
Originally Posted by Der_Idiot View Post
Your car will never make the numbers you want, especially at 9:1 afr. I made 190hp at 9-10:1 and leaned it out and advanced timing some and now I make 280-300 depending on boost. Running it rich will just end up building up huge amounts of carbon deposits.
lol
but did your 190hp feel like THREE HUNDRED FIFTY HORSEPOWER
soviet is offline   Reply With Quote
Old 07-17-2013, 06:57 PM   #86
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,849
Total Cats: 1,788
Default




this pictures is unrelated, i just wanted people to remember when Christian Bale freaked out on mic.
Attached Thumbnails
Compound boost: EFR 7670 into Coldside FFS W/ H20/Meth into 10.5:1 VVT Built Engine-3oytrx.jpg
Braineack is online now   Reply With Quote
Old 07-17-2013, 07:12 PM   #87
Elite Member
iTrader: (1)

Join Date: May 2009
Location: Jacksonville, FL
Posts: 4,682
Total Cats: 216
Default

Attached Thumbnails
Compound boost: EFR 7670 into Coldside FFS W/ H20/Meth into 10.5:1 VVT Built Engine-ac4cb1fbec53df380f0aca10abc14764.gif
Full_Tilt_Boogie is offline   Reply With Quote
Old 07-17-2013, 07:29 PM   #88
Elite Member
iTrader: (2)

miata2fast's Avatar

Join Date: Aug 2009
Location: Dover, FL
Posts: 2,895
Total Cats: 109
Default

[QUOTE=Savington;1032817]I think making serious power (500whp) when your final compressor stage is unintercooled is a pipe dream, no matter what's happening in between the turbo and the supercharger. QUOTE]

With that setup? Alcohol injected, gasoline should only be used for cleaning parts.
miata2fast is offline   Reply With Quote
Old 07-17-2013, 08:05 PM   #89
Supporting Vendor
iTrader: (31)

Savington's Avatar

Join Date: Nov 2006
Location: Sunnyvale, CA
Posts: 14,362
Total Cats: 1,323
Default

Quote:
Originally Posted by SleeperMX-5 View Post
Correct. Thanks for posting that.
I was being facetious, dude. That sort of bullshit might fly on M.net, but if you throw out horsepower numbers here without legitimate dyno charts to back them up, you're not going to have a good day.
Savington is offline   Reply With Quote
Old 07-17-2013, 08:12 PM   #90
Elite Member
Thread Starter
iTrader: (15)

patsmx5's Avatar

Join Date: Aug 2007
Location: Houston, TX
Posts: 8,796
Total Cats: 248
Default

Quote:
Originally Posted by Savington View Post
I was being facetious, dude. That sort of bullshit might fly on M.net, but if you throw out horsepower numbers here without legitimate dyno charts to back them up, you're not going to have a good day.
I haven't posted any HP numbers here. I said I might dyno it. Well see! I do think I'm gonna need to do something about the heat as you said. I don't think water method alone will cut it.
patsmx5 is offline   Reply With Quote
Old 07-17-2013, 08:45 PM   #91
Elite Member

Join Date: Apr 2010
Location: Newcastle, Australia
Posts: 2,638
Total Cats: 25
Default

Quote:
Originally Posted by concealer404 View Post
... on what?

An LSx that made 400whp n/a?


Or are we talking about magical upside-down dynos again?
A litre bike motor on alcohol.

Also except cars with tube frames where there is a lot of space to mount heat exchangers, are people really intercooling both stages separately? It occurs to me that sending very high heat into the cooler will only serve to raise its efficiency, and allow less total intercooler than running 2 smaller ones, one for each stage.

Dann
nitrodann is offline   Reply With Quote
Old 07-17-2013, 09:13 PM   #92
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: NH
Posts: 9,091
Total Cats: 90
Default

Quote:
Originally Posted by nitrodann View Post
A litre bike motor on alcohol.

Also except cars with tube frames where there is a lot of space to mount heat exchangers, are people really intercooling both stages separately? It occurs to me that sending very high heat into the cooler will only serve to raise its efficiency, and allow less total intercooler than running 2 smaller ones, one for each stage.

Dann
Typically they run air/water between stages in cars. I believe the racing skyactiv-D is that way.
Leafy is offline   Reply With Quote
Old 07-17-2013, 09:37 PM   #93
Elite Member

Join Date: Apr 2010
Location: Newcastle, Australia
Posts: 2,638
Total Cats: 25
Default

I wonder why if that actively helps a lot inside the intercooler, or cools before it hits the intercooler.

Im just going off what I know about Delta T vs efficiency.

Dann
nitrodann is offline   Reply With Quote
Old 07-18-2013, 02:07 PM   #94
Elite Member
Thread Starter
iTrader: (15)

patsmx5's Avatar

Join Date: Aug 2007
Location: Houston, TX
Posts: 8,796
Total Cats: 248
Default

Quote:
Originally Posted by thenuge26 View Post
With the complexity of his setup there is about a 0% chance that it will ever be optimized without dyno tuning. Pat is free to not give a **** of course, but we are also free to make fun of him for this fact.
True, it won't be optimized without a dyno. So what? I'm not trying to get every bit of power out of it. The turbo will flow 66 lb/min, I probably won't ask for more than 50. Nothing is set in stone.

After seeing how much interest there is in me putting it on a dyno, I might just have to! Cause I need to impress people on the internet with my dyno sheet, ya know.


On topic, I'm going to have to do some math to estimate the charge temps post-blower with varying levels of boost going into the blower. My big question is, will spraying enough water/meth into the blower keep temps down enough? I would like to think that with enough water, yes, but I got a feeling it's not gonna work as well as I need it to. I would guess I could spray enough water into the blower that it would knock temps down to 212*F more or less with water alone, with water/meth it could be lower. But I think it needs to be down to 120*F to make good power/good driveability with 93 Octane and my compression ratio.

How much boost was magna running with water/meth and no WI?

I feel pretty confident E85 + water injection would work. I just don't want to switch to E85 unless I absolutely have to.
patsmx5 is offline   Reply With Quote
Old 07-18-2013, 02:10 PM   #95
Elite Member
Thread Starter
iTrader: (15)

patsmx5's Avatar

Join Date: Aug 2007
Location: Houston, TX
Posts: 8,796
Total Cats: 248
Default

If I can't make it work with water/meth and 93, I could also drop the compounding and bypass the SC up top. But that would add a bit of complexity getting the control system working for a smooth transition between the two. But that would let me feed 100% intercooled boost to the motor up top. I don't want to do this unless I have to though.
patsmx5 is offline   Reply With Quote
Old 07-18-2013, 02:40 PM   #96
Elite Member
iTrader: (8)

Ryan_G's Avatar

Join Date: Jan 2012
Location: Tampa, Florida
Posts: 2,577
Total Cats: 155
Default

We don't want dyno's because we want to be impressed. We want hard data on how a setup like this performs. It is a relatively unexplored setup.
Ryan_G is offline   Reply With Quote
Old 07-18-2013, 02:58 PM   #97
Elite Member
iTrader: (2)

Join Date: Aug 2012
Location: Indianapolis
Posts: 3,325
Total Cats: 235
Default

The main point of WI is NOT to lower charge temp, it's to increase det resistance. It may lower them some, but again that's not the purpose of it.
thenuge26 is offline   Reply With Quote
Old 07-18-2013, 03:08 PM   #98
Elite Member
Thread Starter
iTrader: (15)

patsmx5's Avatar

Join Date: Aug 2007
Location: Houston, TX
Posts: 8,796
Total Cats: 248
Default

Quote:
Originally Posted by Ryan_G View Post
We don't want dyno's because we want to be impressed. We want hard data on how a setup like this performs. It is a relatively unexplored setup.
I may dyno it to see what it makes. I'm hoping I can keep it compounded and not have to bypass the SC. If I can do that, it should be easier to tune the boost curve and have pretty good torque everywhere without a dip (if I have to bypass SC there will likely be a dip when it happens).
patsmx5 is offline   Reply With Quote
Old 07-18-2013, 03:10 PM   #99
Elite Member
Thread Starter
iTrader: (15)

patsmx5's Avatar

Join Date: Aug 2007
Location: Houston, TX
Posts: 8,796
Total Cats: 248
Default

Quote:
Originally Posted by thenuge26 View Post
The main point of WI is NOT to lower charge temp, it's to increase det resistance. It may lower them some, but again that's not the purpose of it.
Normally, yes. Spraying a ton of it into the blower would probably drop charge temps a good bit though since the air would be really hot and the SC should mix the water well with the charge. I plan to measure charge temps after turbo, after IC and after blower, so if I get all that setup, I'll be able to log the delta T out of the SC with the WI to see how well it's working.
patsmx5 is offline   Reply With Quote
Old 07-18-2013, 03:35 PM   #100
Elite Member
iTrader: (3)

concealer404's Avatar

Join Date: Aug 2011
Posts: 8,460
Total Cats: 782
Default

Time out.

Quote:
FWIW, it trapped 87mph in the 1/8 mile. Car wasn't running too great, but that's what I ran.

Is 87mph in the 1/8 mile special? My daily driver does that, and i'm pretty sure it's not making the 350whp claimed, and it's heavier than a Miata.
concealer404 is offline   Reply With Quote
