Old 11-27-2014, 03:35 PM   #241
Cpt. Slow
iTrader: (25)

curly's Avatar

Join Date: Oct 2005
Location: Oregon City, OR
Posts: 12,107
Total Cats: 518
Default

Torque is already limited to 280 for the 6-speed.

Hell, if he just flips on VICS it's an automatic 13 ft/lbs
curly is offline   Reply With Quote
Old 11-27-2014, 03:37 PM   #242
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 36,185
Total Cats: 2,582
Default

huh? he's got a 6 speed and limiting torque? why?
will this thing see a ton of track duty? I see no need for this unless car is going to be flogged on track repeatedly

*edit:

Blaen, this is probably directed more at you than curly.

Last edited by 18psi; 11-27-2014 at 04:03 PM.
18psi is offline   Reply With Quote
Old 11-27-2014, 03:57 PM   #243
Cpt. Slow
iTrader: (25)

curly's Avatar

Join Date: Oct 2005
Location: Oregon City, OR
Posts: 12,107
Total Cats: 518
Default

Customer got what the customer wanted, you'll have to ask him...
curly is offline   Reply With Quote
Old 11-27-2014, 04:28 PM   #244
Elite Member
Thread Starter
iTrader: (6)

blaen99's Avatar

Join Date: Sep 2010
Location: Seattle, WA
Posts: 4,112
Total Cats: 27
Default

Quote:
Originally Posted by 18psi View Post
huh? he's got a 6 speed and limiting torque? why?
will this thing see a ton of track duty? I see no need for this unless car is going to be flogged on track repeatedly

*edit:

Blaen, this is probably directed more at you than curly.
Because I want to be able to flog it at the track if I want to.

Seriously, I would not have picked up the TSE 25-row oil cooler kit if that wasn't my intention. I would have gone with the 16-row or even stayed with my old kit.

(Edit) And as I think about it, injectors too. There's only 650cc in it right now - and they hit 90% DC in this run from what I understand.
blaen99 is offline   Reply With Quote
Old 11-27-2014, 05:18 PM   #245
Cpt. Slow
iTrader: (25)

curly's Avatar

Join Date: Oct 2005
Location: Oregon City, OR
Posts: 12,107
Total Cats: 518
Default

Very brief rich spike. Closer to a 85% average, but yeah, 350 max with these injectors, and were pretty much there.
curly is offline   Reply With Quote
Old 11-28-2014, 12:00 AM   #246
Elite Member
Thread Starter
iTrader: (6)

blaen99's Avatar

Join Date: Sep 2010
Location: Seattle, WA
Posts: 4,112
Total Cats: 27
Default

Quote:
Originally Posted by nitrodann View Post
Why do the ports with a valve on the end of them flow better than the inlet manifold runners?

What am I misunderstanding?

Dann
The inlet ports without a valve on the end of them, on the unmodified VICS manifold, that direct flow through a helmholtz chamber, do significantly better then the intlet ports that do have a valve, and that use the helmholtz chamber as an intake.

Frankly, I'm not surprised at the results - I told Curly up front that I seriously doubted there would be any gains. My surprise, however, is how drastic the losses are - close to a 10% difference in the advantage of the unmodified VICS.

From the RX7 world, I know it's hard to improve on Mazda manifolds. While it's possible to design a good long/short runner setup (Check out the 89-91 NA rx7 manifolds), looking at the psuedo-gutted design, it's pretty obvious it's going to run into problems with how it will direct air. Frankly, I seriously doubt us enthusiasts can meaningfully improve on OEM Mazda intake manifolds due to previous experience with them.
blaen99 is offline   Reply With Quote
Old 11-28-2014, 12:50 AM   #247
Cpt. Slow
iTrader: (25)

curly's Avatar

Join Date: Oct 2005
Location: Oregon City, OR
Posts: 12,107
Total Cats: 518
Default

From what the tuner said, he either suspects it's giving crazy resonance with the extra volume, or it's just simply killing volumetric efficiency. Or those are the same thing, and everything the tuner was saying was going over my head. That's a strong possibility too.
curly is offline   Reply With Quote
Old 11-28-2014, 02:30 PM   #248
Junior Member
iTrader: (4)

Join Date: Apr 2014
Location: QC, CANADA
Posts: 130
Total Cats: 4
Default

sorry to hop in the thread and jack the **** out of it.

but, did you say VICS and 13 ft/lb right there? So just gutting it and have immediate gains?
Cheekanuble is offline   Reply With Quote
Old 11-28-2014, 02:37 PM   #249
Cpt. Slow
iTrader: (25)

curly's Avatar

Join Date: Oct 2005
Location: Oregon City, OR
Posts: 12,107
Total Cats: 518
Default

Gutted upper manifold was a 30hp loss above 5500rpm.

We set VICs to open at 1000 and then 8000 to see where they cross. It was still 5500 as every other dyno thread in the past has shown, that's what Mazda tuned the manifold for.

With his current tune, if he activated VICs at 5500, he'd gain 13ft/lbs, but that's over his limit of 280, so we left it "deactivated".

We could have activated it and turned down the boost, but my tuner has the experience, and he said it wouldn't of been a good idea to limit the turbo right when it's trying to spool up.
curly is offline   Reply With Quote
Old 11-28-2014, 02:48 PM   #250
Junior Member
iTrader: (4)

Join Date: Apr 2014
Location: QC, CANADA
Posts: 130
Total Cats: 4
Default

interesting, thanks for clearing that up curly.
Cheekanuble is offline   Reply With Quote
Old 11-28-2014, 02:49 PM   #251
Elite Member
iTrader: (8)

Join Date: Dec 2008
Location: Kingston, Ontario
Posts: 2,791
Total Cats: 71
Default

Quote:
Originally Posted by blaen99 View Post

I'll talk to him on his suggestions then...
tubular exhaust manifold with a real collector and a proper intake manifold.

I know where you can get them too.
shlammed is offline   Reply With Quote
Old 11-28-2014, 11:58 PM   #252
Supporting Vendor
iTrader: (31)

Savington's Avatar

Join Date: Nov 2006
Location: Sunnyvale, CA
Posts: 14,363
Total Cats: 1,323
Default

Quote:
Originally Posted by blaen99 View Post
Frankly, I seriously doubt us enthusiasts can meaningfully improve on OEM Mazda intake manifolds due to previous experience with them.
lol wut?

https://www.miataturbo.net/engine-pe...e7/#post632316
Savington is offline   Reply With Quote
Old 11-29-2014, 01:08 AM   #253
Cpt. Slow
iTrader: (25)

curly's Avatar

Join Date: Oct 2005
Location: Oregon City, OR
Posts: 12,107
Total Cats: 518
Default

I think he means by modifying oem manifolds. Technically you're not modifying with the above, you're just making a pre-made manifold fit.
curly is offline   Reply With Quote
Old 11-29-2014, 01:43 AM   #254
Elite Member
Thread Starter
iTrader: (6)

blaen99's Avatar

Join Date: Sep 2010
Location: Seattle, WA
Posts: 4,112
Total Cats: 27
Default

^This.

Sav,, I think it was pretty obvious that I was specific to modified Mazda manifolds in the post...come on mang. Of course there's tons of better manifolds, but I find it seriously doubtful we end up gutting our way to an improved stock manifold.
blaen99 is offline   Reply With Quote
Old 11-29-2014, 03:08 AM   #255
Supporting Vendor
iTrader: (31)

Savington's Avatar

Join Date: Nov 2006
Location: Sunnyvale, CA
Posts: 14,363
Total Cats: 1,323
Default

Ah. Yes, I misread/misunderstood.

There are definitely improvements to be had on stock manifolds if you know what you're doing. Hand one to Jesse Prather along with a check for about $2000 and you'll get quite a gem of a USDM manifold back.
Savington is offline   Reply With Quote
Old 11-29-2014, 07:48 AM   #256
Moderator
iTrader: (11)

sixshooter's Avatar

Join Date: Nov 2008
Location: Tampa, Florida
Posts: 15,669
Total Cats: 1,560
Default

Lol. And an amazing :coughcough: "stock" cylinder head.
sixshooter is offline   Reply With Quote
Old 11-29-2014, 10:04 AM   #257
Cpt. Slow
iTrader: (25)

curly's Avatar

Join Date: Oct 2005
Location: Oregon City, OR
Posts: 12,107
Total Cats: 518
Default

I'm guessing some simple port matching wouldn't hurt, but that gets into head work as well.

If a CNC head really is in your future, I'd probably suggest having emilio port a square top and install the two together. This would all seem a little silly without sometime like the Hellafab manifold mentioned earlier.

curly is offline   Reply With Quote
Old 11-29-2014, 11:38 AM   #258
Elite Member
Thread Starter
iTrader: (6)

blaen99's Avatar

Join Date: Sep 2010
Location: Seattle, WA
Posts: 4,112
Total Cats: 27
Default

Quote:
Originally Posted by Savington View Post
Ah. Yes, I misread/misunderstood.

There are definitely improvements to be had on stock manifolds if you know what you're doing. Hand one to Jesse Prather along with a check for about $2000 and you'll get quite a gem of a USDM manifold back.
Granted, but Jesse Prather isn't exactly one of us randomly gutting the manifold with no real knowledge about what he's doing.

Quote:
Originally Posted by curly View Post
I'm guessing some simple port matching wouldn't hurt, but that gets into head work as well.

If a CNC head really is in your future, I'd probably suggest having emilio port a square top and install the two together. This would all seem a little silly without sometime like the Hellafab manifold mentioned earlier.
Let's just say what I'm considering for the future might be a bit of a surprise for this forum.

We'll talk RL, as I have no interest in going into potential Faefae or nitrodann territory on the forums.
blaen99 is offline   Reply With Quote
Old 12-01-2014, 01:18 AM   #259
Elite Member
Thread Starter
iTrader: (6)

blaen99's Avatar

Join Date: Sep 2010
Location: Seattle, WA
Posts: 4,112
Total Cats: 27
Default

So,

Overall impressions: I know why 18psi said a 400rwhp miata made him paranoid.


Curly did a very good job on cleaning up stuff, and surpassed all of my expectations quite frankly.

And now, I'm going to bed. 'Cause Seattle drivers are difficult to explain just how bad they are, and after a few hours of driving with them, I'm done.
Attached Thumbnails
Blaen's because 350hp build-1305147915969.jpg
blaen99 is offline   Reply With Quote
Old 12-01-2014, 12:26 PM   #260
Elite Member
Thread Starter
iTrader: (6)

blaen99's Avatar

Join Date: Sep 2010
Location: Seattle, WA
Posts: 4,112
Total Cats: 27
Default

So, now that I'm not wiped out by Seattle drivers on the Sunday after thanksgiving (Bay Area drivers at least made logical decisions when I was down there.....Not so much the Seattle ones)

First off, 350rwhp may be a bit much for something I drive daily. Fortunately, it's not my long-term plan for this to be a DD - I was in the process of buying a new car, the Evo X included. The Evo X is probably out of my list now. Actually, right now I'm a giant quivering wuss from having to drive home in that traffic in that, so for the next week, anything over 120rwhp is probably off the list. That'll likely change in a month or two, but my DD horsepower desires are definitely much lower in this traffic/area then they were after driving this Miata.

Secondly, I think the Skunk2 throttle body seems to require much finer modulation than the stock Miata throttle body. It's definitely going to take some getting used to. I don't know if I'd recommend it on a DD now - I picked it up so that people wouldn't go "But the throttle body is the restriction!!!!!!" in the back to back tests of psuedo-gutted vs non-gutted manifolds.

Thirdly, I now officially spin tires in 3rd at 4k, and found out I can spin it in 4th if I REALLY want to on the way home (Could have been roads, dunno, I really wanted to get by a Audi that was being an *******). That's just wrong on every level.

Fourth and finally? I think I'm done with looking for more power. I'll probably be looking to improve spool, but I think Curly was right - 350rwhp is a real kick in the pants.
blaen99 is offline   Reply With Quote
