Default Splitime's VQ35DE build. Miotta goes V6 :)

So I've had this random drivetrain sitting in my garage since I bought it ... a year and a half ago.... and some. It was intended to power a Grassroots Motorsports Challenge car build. Through a few events (buying a 323 GTX, then buying a second...) of chance, I decided to thin the herd and sold off the Miata shell I had in the driveway for the build. Right around the GTX buying time, new turbo kits turbo was bad and I decided to change the path for the track car. I figured why not use the really fun drivetrain in the track car.

So track car Miotta VQ35 was born (vs my pseudo secret plans for the GRM build). I've had the car on jackstands and the drivetrain out for a few months. Don't expect this to be a super fast build.

Did another round of moving crap around, taking stock of parts, evaluating what I'm getting into etc... List is something like this:
Engine mounts (cutting subframe, possible steering rack moving)
Trans mount (will be done off of the bolt over framerail reinforcements)
Rear diff front mount (using Rx7 gsl 7" clutch type for super cheapness)
Wiring for e-pedal/harness adjustments/ecu reflash (security removal + tune)
Adjust fuel system for return style
Manifold Connector for turbo (assuming it fits... flipping OEM headers for cheapness)
Bang/crush/pinch/hammer/bang alot more... frame rails to fit frame rail reinforcement dealies
Downpipe (will build to replace turbo at first, NA to get everything working)
Exhaust
Transmission shifter relocation (shorten linkage and modify shifter holder)
Custom driveshaft (cutting up CF 350z driveshaft and rx7 rear, sending out to be built)
Install E-Pedal
Install new ISC tophats for rear
Rip out both subframes, clean up and install Delrin bushing LCA set.
Make mounts for HID projector ebay junk
Trim engine bay frame rails (don't expect to need clearance but doing it while I stitch welds up, and then paint)
Lots and lots of other random crap that will slowly drive me nuts all winter long.

I plan on and hope to have this ready for next track season. Initial plan is to prep the build for turbo... but run it NA for awhile so I can debug everything. I figure about 250whp NA will be fine for a bit anyways . Turbo will be a nice clean Holset HX35W I picked up... figure 400 with a silly powerband/torque curve will be fun.

Here are some pictures to show I actually moved stuff around.. and uh... started....

Organized chaos

After some clean up, junking Turbo Capri motor, old miata motor on stand, bringing everything out.














Did I mention that this won't be a fast build?
Splitime is offline   Reply With Quote
Old 10-14-2010, 01:48 AM   #2
Cpt. Slow
iTrader: (25)

curly's Avatar

Join Date: Oct 2005
Location: Oregon City, OR
Posts: 12,109
Total Cats: 518
Default

Love it. My prediction though? Looking at mighty mouse's build, among many others, you're hoping for track season 2011, but I'm going to guess track season 2012.
curly is offline   Reply With Quote
Old 10-14-2010, 02:10 AM   #3
Elite Member
iTrader: (8)

Join Date: Aug 2007
Location: Bellingham, Wa
Posts: 2,732
Total Cats: 3
Default

Quote:
Originally Posted by curly View Post
Love it. My prediction though? Looking at mighty mouse's build, among many others, you're hoping for track season 2011, but I'm going to guess track season 2012.
No way. This is splitime. He'll get it done by 2011. Just in the nick of time.

This is going to be good. You've always been an outside of the box thinker, this is the best so far.
wayne_curr is offline   Reply With Quote
Old 10-14-2010, 02:11 AM   #4
Elite Member
iTrader: (7)

Join Date: Jul 2009
Location: Gainesville,Fl
Posts: 3,354
Total Cats: 7
Default

This is something special. Subscribed and Good luck!
turotufas is offline   Reply With Quote
Old 10-14-2010, 03:27 AM   #5
Elite Member
iTrader: (13)

Join Date: Dec 2006
Location: Taos, New mexico
Posts: 5,703
Total Cats: 237
Default

I've been waiting for you to tell us your evil plans for the miotta. Impressive, subscribed sir.
Fireindc is offline   Reply With Quote
Old 10-14-2010, 09:12 AM   #6
Elite Member
iTrader: (2)

miata2fast's Avatar

Join Date: Aug 2009
Location: Dover, FL
Posts: 2,899
Total Cats: 109
Default

Can't wait to see the results.
miata2fast is offline   Reply With Quote
Old 10-14-2010, 09:18 AM   #7
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,899
Total Cats: 1,792
Default

Quote:
Originally Posted by wayne_curr View Post
No way. This is splitime. He'll get it done by 2011. Just in the nick of time.

This is going to be good. You've always been an outside of the box thinker, this is the best so far.
He's probably been sitting on this build for at least a year. I predict late 2012.
Braineack is offline   Reply With Quote
Old 10-14-2010, 09:52 AM   #8
Miotta FTW!
Thread Starter
iTrader: (24)

Splitime's Avatar

Join Date: Jun 2006
Location: Chicagoland, IL
Posts: 4,295
Total Cats: 26
Default

Quote:
Originally Posted by Braineack View Post
He's probably been sitting on this build for at least a year. I predict late 2012.
Over a year for another car though, which never got started because I wanted this car back on track first.

All has changed
Splitime is offline   Reply With Quote
Old 10-14-2010, 09:53 AM   #9
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,899
Total Cats: 1,792
Default

Now that my discouraging words have demotivated you...
Braineack is offline   Reply With Quote
Old 10-14-2010, 10:08 AM   #10
Elite Member
iTrader: (9)

Join Date: Sep 2008
Location: Livonia, Michigan
Posts: 5,684
Total Cats: 10
Default

Name:  mother-of-god-super-troopers.jpg
Views: 261
Size:  27.3 KB

In for badass track car re-built with a new power plant and drivetrain

Happy?

Last edited by buffon01; 10-14-2010 at 10:18 AM.
buffon01 is offline   Reply With Quote
Old 10-14-2010, 10:15 AM   #11
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,899
Total Cats: 1,792
Default

It's already a purpose driven track car...just needs a new power plant and drivetrain
Braineack is offline   Reply With Quote
Old 10-14-2010, 10:19 AM   #12
Elite Member
iTrader: (10)

leatherface24's Avatar

Join Date: Dec 2006
Location: Pembroke Pines
Posts: 4,033
Total Cats: 2
Default

Man its good to see you're finally getting this rolling
leatherface24 is offline   Reply With Quote
Old 10-14-2010, 10:23 AM   #13
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,899
Total Cats: 1,792
Default

I see Delrin:

Braineack is offline   Reply With Quote
Old 10-14-2010, 10:38 AM   #14
Miotta FTW!
Thread Starter
iTrader: (24)

Splitime's Avatar

Join Date: Jun 2006
Location: Chicagoland, IL
Posts: 4,295
Total Cats: 26
Default

Quote:
Originally Posted by Braineack View Post
I see Delrin:
Yup, its also in my build list up top
Splitime is offline   Reply With Quote
Old 10-14-2010, 10:43 AM   #15
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,899
Total Cats: 1,792
Default

we all know by now i cant read.
Braineack is offline   Reply With Quote
Old 10-14-2010, 11:14 AM   #16
Elite Member
iTrader: (5)

Join Date: Oct 2007
Location: Canton, Ga
Posts: 1,707
Total Cats: 19
Default

whats up with the window A/C unit laying on the floor? new interfooler?

this will be awesome.
Stealth97 is offline   Reply With Quote
Old 10-14-2010, 11:30 AM   #17
Elite Member
iTrader: (10)

rccote's Avatar

Join Date: Jan 2008
Location: Buffalo NY
Posts: 1,595
Total Cats: 17
Default

Cat's out of the bag.
rccote is offline   Reply With Quote
Old 10-14-2010, 11:46 AM   #18
Junior Member

Join Date: Oct 2005
Posts: 84
Total Cats: 0
Default

bad asssssssssss. we had a guy come to us with this idea at our shop but we turned him down becuase we had too much work to start something we've never done before and removing all the security stuff from the harness is hard as hell...this looks promising! i am def suscribing to see how this goes!!!

i love driving my buddies supercharged 350z. it moves like crazy and feels awesome but i hate how the 350z handles! so if you mate awesome handing and great power you got yourself a pretty badass little track car man.
Jeepster118 is offline   Reply With Quote
Old 10-14-2010, 12:00 PM   #19
Miotta FTW!
Thread Starter
iTrader: (24)

Splitime's Avatar

Join Date: Jun 2006
Location: Chicagoland, IL
Posts: 4,295
Total Cats: 26
Default

Quote:
Originally Posted by Jeepster118 View Post
bad asssssssssss. we had a guy come to us with this idea at our shop but we turned him down becuase we had too much work to start something we've never done before and removing all the security stuff from the harness is hard as hell...this looks promising! i am def suscribing to see how this goes!!!

i love driving my buddies supercharged 350z. it moves like crazy and feels awesome but i hate how the 350z handles! so if you mate awesome handing and great power you got yourself a pretty badass little track car man.
Security stuff will basically be deleted. Even though I have an entire 350z wiring harness and security components. After going over lots of options, settled on an UpRev reflash. A buddy will handle that and while deleting the NATS stuff, it'll get a quick tune adjustment and a tweak to the e-throttle settings so it responds like a real throttle.
Splitime is offline   Reply With Quote
Old 10-14-2010, 12:43 PM   #20
Junior Member
iTrader: (4)

Join Date: Jan 2008
Location: South Carolina
Posts: 262
Total Cats: 0
Default

Good for you man. I did some serious crunching of numbers and thought processing on this swap for about two weeks and decided not to do it. I just could not forcast this kind of time into my schedule with a 13 month old and constantly traveling for my job.

Good luck!!!!

So, Mr. Envy here prob subscribing to this thread now.
localtech is offline   Reply With Quote
