Old 04-06-2008, 06:51 PM   #121
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,860
Total Cats: 1,788
Default

I heard it once i had my head over the engine bay and not inside the cabin.


Lars, get that exhaust soon, because ill wanna take mine to a steady state within a few weeks then we can cure your torque drop issues
Braineack is offline   Reply With Quote
Old 04-06-2008, 10:02 PM   #122
Supporting Vendor
iTrader: (31)

Savington's Avatar

Join Date: Nov 2006
Location: Sunnyvale, CA
Posts: 14,363
Total Cats: 1,323
Default

I know a bunch of people have had trouble, but I got my Knocksense dialed in with an extra potentiometer (thanks Chad) to give me a bunch of control over its sensitivity, and it's on the money. Every time I see that light go on, the little marbles start rattling at the same time, and if the light is off, I can't ever hear anything.

This week I am going to use the dipstick-in-plug #1 trick to check and see whether my crank pulley timing mark is way off or something. I'll report back.
Savington is offline   Reply With Quote
Old 04-06-2008, 10:20 PM   #123
Elite Member
iTrader: (3)

AbeFM's Avatar

Join Date: Aug 2006
Location: San Diego, CA
Posts: 3,048
Total Cats: 8
Default

Quote:
Originally Posted by Savington View Post
I know a bunch of people have had trouble, but I got my Knocksense dialed in with an extra potentiometer (thanks Chad) to give me a bunch of control over its sensitivity, and it's on the money. Every time I see that light go on, the little marbles start rattling at the same time, and if the light is off, I can't ever hear anything.

This week I am going to use the dipstick-in-plug #1 trick to check and see whether my crank pulley timing mark is way off or something. I'll report back.
What what what? Explain this please! I was just going to try the hybrid map myself (though with CA 91 I'm not sure what to do), and my knocksense is my limitation. I'd love to know how to tune it better. There's 1 pot in it, is that what you're talkingabout?

Please explain in detail!!

And if anyone has an idea on timing (I'm thinking 2 degrees timing out everywhere save for the bottom two rows) please let me know!!
AbeFM is offline   Reply With Quote
Old 04-07-2008, 12:15 AM   #124
Elite Member
iTrader: (13)

cjernigan's Avatar

Join Date: Oct 2006
Location: Atlanta, GA
Posts: 8,147
Total Cats: 6
Default

Abe, you install the 10k ohm pot in the knock sensor line going to the knocksense. This allows you more adjustment with the knocksense. Most the time the knocksense picks up to many little engine noises to be useful. The extra pot allows you to adjust that sensitivity out.
If you look at the instructions that came with the knock sense it will tell you more about it.
cjernigan is offline   Reply With Quote
Old 04-08-2008, 01:46 AM   #125
Junior Member

Join Date: Mar 2007
Location: Chile
Posts: 95
Total Cats: 0
Default

Thanx all for the maps!
I tried hybrid map and the diference is amazing.
First off all, smoooooth. from 2000 RPM to red line is a lot better than the MSPnP table. In hard acelerations and cruise very good.
Second. my buttometer feel the car much faster. I donīt hear any ping or something strange.
macanha is offline   Reply With Quote
Old 04-08-2008, 08:45 AM   #126
Ben
Supporting Vendor
iTrader: (33)

Ben's Avatar

Join Date: Jul 2006
Location: atlanta-ish
Posts: 12,689
Total Cats: 99
Default

I'm just waiting for the "why is my motor making funny noises and spewing smoke?" thread
Ben is offline   Reply With Quote
Old 04-08-2008, 09:09 AM   #127
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,860
Total Cats: 1,788
Default

Quote:
Originally Posted by cjernigan View Post
Abe, you install the 10k ohm pot in the knock sensor line going to the knocksense. This allows you more adjustment with the knocksense. Most the time the knocksense picks up to many little engine noises to be useful. The extra pot allows you to adjust that sensitivity out.
If you look at the instructions that came with the knock sense it will tell you more about it.

well shoot, i sold mine because it always heard too much noise....
Braineack is offline   Reply With Quote
Old 04-08-2008, 11:22 AM   #128
Elite Member
iTrader: (15)

Join Date: Dec 2007
Location: San Antonio, Texas
Posts: 4,889
Total Cats: 28
Default

Quote:
Originally Posted by cjernigan View Post
Abe, you install the 10k ohm pot in the knock sensor line going to the knocksense. This allows you more adjustment with the knocksense. Most the time the knocksense picks up to many little engine noises to be useful. The extra pot allows you to adjust that sensitivity out.
If you look at the instructions that came with the knock sense it will tell you more about it.
So this is another potentiometer in addition to the one already on the circuit board? If so, I suppose one becomes a coarse gain adjuster and one becomes a fine gain adjuster? I don't remember seeing this in the instructions but I'll look again. At any rate it would be nice to have another pot that can be remotely mounted for easier adjustment access. Thanks Chad.
ZX-Tex is offline   Reply With Quote
Old 04-08-2008, 11:50 AM   #129
Elite Member
iTrader: (13)

cjernigan's Avatar

Join Date: Oct 2006
Location: Atlanta, GA
Posts: 8,147
Total Cats: 6
Default

cjernigan is offline   Reply With Quote
Old 04-08-2008, 11:58 AM   #130
Junior Member

Join Date: Mar 2007
Location: Chile
Posts: 95
Total Cats: 0
Default

Quote:
Originally Posted by Ben View Post
I'm just waiting for the "why is my motor making funny noises and spewing smoke?" thread
hehehe.

It is working and proved for others miatas, why not me?.
Why all of us put a turbo in a N/A car? is not safety .!
I already have 0.7 Bar and I don't have planed to put much more presure.
Also I have a very conservative AFR at boost (10.5). Why it should be a problem for my engine?
macanha is offline   Reply With Quote
Old 04-08-2008, 12:10 PM   #131
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,860
Total Cats: 1,788
Default

its been my experience that 10.5:1 AFR is pretty harmful.
Braineack is offline   Reply With Quote
Old 04-08-2008, 12:51 PM   #132
Miotta FTW!
iTrader: (24)

Splitime's Avatar

Join Date: Jun 2006
Location: Chicagoland, IL
Posts: 4,295
Total Cats: 26
Default

Crap, so many different starting points for Spark maps... what to use what to use....

<-- must get this basemap ready... so I actually get my *** out and tuning.
Splitime is offline   Reply With Quote
Old 04-08-2008, 01:12 PM   #133
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,860
Total Cats: 1,788
Default

Quote:
Originally Posted by Braineack View Post
its been my experience that 10.5:1 AFR is pretty harmful.
If the increased quantity of fuel is great enough, it can "wash" the film of oil from the cylinder walls, prior to ignition. This leaves ring-to-cylinder metal on metal. The other byproduct of fuel washing past the piston rings is that the fuel gets into the oil. Fuel is a horrible lubricant, does not protect surfaces well at all.

Plenty of members here running FMUs and high boost have blown motors without knock. I blame most of it on the fact that we ran over 11:1 for long periods of time.
Braineack is offline   Reply With Quote
Old 04-08-2008, 01:28 PM   #134
Elite Member
iTrader: (13)

cjernigan's Avatar

Join Date: Oct 2006
Location: Atlanta, GA
Posts: 8,147
Total Cats: 6
Default

Do not use a 10k ohm pot for this mod. Follow these directions, straight from Boris himself.

cjernigan is offline   Reply With Quote
Old 04-08-2008, 04:18 PM   #135
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Chicago (Over two miles from Wrigley Field. Fuck the Cubs. Fuck them in their smarmy goat-hole.)
Posts: 26,317
Total Cats: 1,915
Default

Steering the thread back onto course (I think) it occured to me that I don't think I've actually seen a map of FM's timing settings for the link in a manner that's easily comprehensible. So I made one.

Attached is an XL file that I created using FM's "1.6, 440cc, Turbo" link defaults. I started with the specific RPM/MAP datapoints that they provided and performed a linear interpolation between those cells at increments of 10kPa and 100 RPM. This way you can easily find out what the equivalents value would be for cells that fall between stated values.

Some might call it a conservative map, but it looks pretty ordinary to me. This morning, for instance, I finally got some ping out of my engine at 183 kPa at about 5,500 RPM. My advance at the time was 18° and while this is on 91 octane, it's also with water injection.

I never heard it, but the KnockSenseMS picked it up.
Attached Files
File Type: zip FM 1.6 Link Turbo.zip (15.2 KB, 176 views)
Joe Perez is offline   Reply With Quote
Old 04-08-2008, 04:27 PM   #136
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,860
Total Cats: 1,788
Default

I've already done that years ago


Braineack is offline   Reply With Quote
Old 04-08-2008, 04:30 PM   #137
Elite Member
iTrader: (14)

Join Date: Mar 2006
Location: Edmonton, AB
Posts: 4,921
Total Cats: 0
Default

I've been able to add 4* across the entire FM map with out any significant increase in ping. Only saw ping once my I/C had heat soaked during autocross.
jayc72 is offline   Reply With Quote
Old 04-08-2008, 04:41 PM   #138
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Chicago (Over two miles from Wrigley Field. Fuck the Cubs. Fuck them in their smarmy goat-hole.)
Posts: 26,317
Total Cats: 1,915
Default

Quote:
Originally Posted by Braineack View Post
I've already done that years ago
You utter ***.

Wait until someone kills an hour of hard work and then reveal that it's been done...
Joe Perez is offline   Reply With Quote
Old 04-08-2008, 04:53 PM   #139
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,860
Total Cats: 1,788
Default

I'll make it up to you with a pirate duck:




also, fwiw, the old thread "settings" that was a sticky had the same map posted for a really long time too
Attached Thumbnails
Dyno Tuning, Take a Look FM we want your timingz-pirateduck.jpg
Braineack is offline   Reply With Quote
Old 04-08-2008, 05:06 PM   #140
Miotta FTW!
iTrader: (24)

Splitime's Avatar

Join Date: Jun 2006
Location: Chicagoland, IL
Posts: 4,295
Total Cats: 26
Default

Quote:
Originally Posted by Braineack View Post
I'll make it up to you with a pirate duck:
For some reason I want that duck made into a sticker and put on my car.
Splitime is offline   Reply With Quote
