Old 02-22-2013, 12:21 PM   #81
y8s
2 Props,3 Dildos,& 1 Cat
iTrader: (8)

y8s's Avatar

Join Date: Jun 2005
Location: Fake Virginia
Posts: 19,038
Total Cats: 407
Default

not sure how this will affect vibration significantly.

assumptions I'm making:

1. the manifold stiffness is >> the crane stiffness (thick tubing with large section vs. lil pipey)
2. vibration amplitude can only be decreased by:
a) reducing the excitor (engine vibration, chassis vibration)
b) isolation of the excitor from the target
c) moving the resonance frequency of the target far away from the excitor frequency(ies)

The cranes don't really do any of those. They DO provide a little bit of load bearing capability against the weight of the turbo / mani, but that's pretty much it.

If you want reduce vibes, you can really only increase stiffness (reinforcements, cranes) of the system or increase mass of the system. I'd argue that increasing stiffness will only raise the resonant frequency of the vibration to a higher rev range, and not above the working conditions.

adding mass will probalby help but might make the weight load much worse than it already is. But if you're building a crane, might as well build a bigger crane!
y8s is offline   Reply With Quote
Old 02-22-2013, 12:26 PM   #82
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: NH
Posts: 9,091
Total Cats: 90
Default

The crane by itself might not be very stiff, but Look at what it does to the geometry of the whole package and how that changes sitffness. I can go out the the fase car and cut one or two 1/2" thin wall tubes and turn that chassis from a raging hard on to a flaccid piece of ****.
Leafy is offline   Reply With Quote
Old 02-22-2013, 12:47 PM   #83
Elite Member
iTrader: (9)

TurboTim's Avatar

Join Date: Jun 2006
Location: Chesterfield, NJ
Posts: 6,484
Total Cats: 248
Default

Wrap the manifold with dynamat. A few boxes worth.
TurboTim is offline   Reply With Quote
Old 02-23-2013, 11:22 AM   #84
Senior Member
iTrader: (10)

Join Date: Jul 2009
Location: Oakdale, CA
Posts: 1,353
Total Cats: 66
Default

So is a crane worth it for preventative reasons on a car that will see a lot of street time but will also have 8-10 race weekends on it a year?
RyanRaduechel is offline   Reply With Quote
Old 02-23-2013, 11:34 AM   #85
Elite Member
iTrader: (3)

Join Date: Mar 2008
Location: Granbury, TX
Posts: 6,009
Total Cats: 583
Default

Unless you've characterized the problem with an engineering analysis and know exactly what you're trying to address . . . no.

If you look at those F1 cranes from the '80s Renault engines, you'll notice:
1. The turbo components are large and at extended moment arms away from the engine (not a compact log manifold);
2. There were no structural elements available for bracing (in our case, downpipes run along the engine and transmission offering a lot of good places for effective braces/supports);
3. They did finite element analyses and vibration analyses. They knew exactly what they were trying to address and designed the lightest possible effective supports. None of that preliminary engineering work has been done here.

The effective solution for Miatas is a downpipe brace secured by the transmission bolts. Especially when running a log manifold and Inconel studs. I think what Curly is trying to do here is relieve some of the tension on his top turbo studs, but I doubt it's needed. In comparison to the strength of the log manifold, those braces are low-strength.

Simpler = Better.
hornetball is offline   Reply With Quote
Old 02-23-2013, 11:41 AM   #86
Senior Member
iTrader: (10)

Join Date: Jul 2009
Location: Oakdale, CA
Posts: 1,353
Total Cats: 66
Default

Alrighty then, thank you for the detailed answer.
RyanRaduechel is offline   Reply With Quote
Old 02-23-2013, 12:17 PM   #87
Cpt. Slow
Thread Starter
iTrader: (25)

curly's Avatar

Join Date: Oct 2005
Location: Oregon City, OR
Posts: 12,107
Total Cats: 518
Default

Yup, Just looking for a little stud support. An exercise in fabrication as well.
curly is offline   Reply With Quote
Old 02-23-2013, 12:41 PM   #88
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,860
Total Cats: 1,788
Default

using the center bolt is going to be REALLY hard for him.
Braineack is offline   Reply With Quote
Old 02-23-2013, 01:54 PM   #89
Tour de Franzia
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

Quote:
Originally Posted by curly View Post
Yup, Just looking for a little stud support.
Attached Thumbnails
Pictures of my rod for Hustler-542707_341135009330986_1250718343_n.jpg
hustler is offline   Reply With Quote
Old 03-07-2013, 01:24 AM   #90
Senior Member
iTrader: (3)

Join Date: Nov 2011
Location: Beaverton, OR
Posts: 737
Total Cats: 30
Default

^wow, way to gay it up
greddygalant is offline   Reply With Quote
Old 03-07-2013, 01:49 AM   #91
Tour de Franzia
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

Quote:
Originally Posted by greddygalant View Post
^wow, way to gay it up
Did you climax without the funnel mask for the first time in your pathetic life?
hustler is offline   Reply With Quote
