Old 11-04-2011, 01:17 PM   #21
Elite Member
iTrader: (41)

Join Date: Jan 2006
Location: Seabrook, TX
Posts: 2,409
Total Cats: 19
Default



I would be excited to see the dyno plot myself once made public. I have toyed with the idea of using a tuned N/A VVT motor in my Exocet, but will be going the way of a turbo motor.

It always makes me happy to see the attention to detail that seems to be put into this car. It makes me even happier to see it done by a group of guys that you know are doing it themselves to race against some of the factory backed teams. Kudos.
Attached Thumbnails
rharris19 is offline   Reply With Quote
Old 11-04-2011, 01:36 PM   #22
Elite Member
iTrader: (10)

Join Date: Oct 2008
Location: Seattle, Wa
Posts: 1,780
Total Cats: 30
Default

The solid state relay system makes me wet. Super impressive car.
Jeff_Ciesielski is offline   Reply With Quote
Old 11-04-2011, 03:52 PM   #23
Elite Member
iTrader: (12)

GeneSplicer's Avatar

Join Date: Sep 2009
Location: Birmingham, AL
Posts: 2,006
Total Cats: 147
Default

Those must be some pretty dam bright LEDs to house them behind the lens... same ones you had mounted on the hood last year?
GeneSplicer is offline   Reply With Quote
Old 11-04-2011, 04:18 PM   #24
Supporting Vendor
iTrader: (3)

Join Date: Jul 2006
Location: San Diego
Posts: 2,862
Total Cats: 484
Default

^ I believe they also mount a second pair of those LEDs in the bumper opening for a total of 4.
ThePass is offline   Reply With Quote
Old 11-04-2011, 04:28 PM   #25
Trackspeed Engineering
iTrader: (9)

Join Date: Jan 2008
Location: Bay Area, California
Posts: 937
Total Cats: 10
Default

Quote:
Originally Posted by ThePass View Post
^ I believe they also mount a second pair of those LEDs in the bumper opening for a total of 4.
Correct.
crashnscar is offline   Reply With Quote
Old 11-04-2011, 04:46 PM   #26
Supporting Vendor
iTrader: (10)

Reverant's Avatar

Join Date: Jun 2006
Location: Athens, Greece
Posts: 5,440
Total Cats: 198
Default

Wow, that smartwire unit is really expensive. Unless someone uses all the channels it provides, it might be more economical to go with OTS solid state relays.
Reverant is offline   Reply With Quote
Old 11-04-2011, 05:04 PM   #27
Tour de Franzia
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

Quote:
Originally Posted by ThePass View Post
^ I believe they also mount a second pair of those LEDs in the bumper opening for a total of 4.
I will mount your bumper opening.
hustler is offline   Reply With Quote
Old 11-04-2011, 07:15 PM   #28
Elite Member
iTrader: (9)

TurboTim's Avatar

Join Date: Jun 2006
Location: Chesterfield, NJ
Posts: 6,483
Total Cats: 248
Default

Quote:
Originally Posted by JasonC SBB View Post
I guess you should use VVT to limit topend power to the rules.
Yeah, this is what I was thinking. I guess we'll see eventually.

Very nice job Emilio.
TurboTim is offline   Reply With Quote
Old 11-04-2011, 07:33 PM   #29
Elite Member
iTrader: (9)

Join Date: Aug 2006
Location: Concord, North Carolina
Posts: 4,172
Total Cats: 5
Default

Damn. Nicely done guys. I've always wanted an obnoxiously orange miata.
miatamania is offline   Reply With Quote
Old 11-04-2011, 08:03 PM   #30
Senior Member
iTrader: (6)

Join Date: Aug 2009
Location: Charlotte, NC
Posts: 924
Total Cats: 16
Default

I need to change my pants now. Looks absolutely amazing Emilio! As always, best of luck out there!

Quote:
Originally Posted by miatamania View Post
Damn. Nicely done guys. I've always wanted an obnoxiously orange miata.

1990 Miata: In pieces waiting on paint
Do it ******~!
Gryff is offline   Reply With Quote
Old 11-04-2011, 11:42 PM   #31
Junior Member
iTrader: (1)

Join Date: Aug 2007
Posts: 387
Total Cats: 10
Default

Quote:
Originally Posted by AnnorexicRoadster View Post
I always thought modern day ABS was faster then not having ABS.
that's the key. there is nothing modern about the ABS unit in Crusher. that is probably a 15 years old design at best.
bellwilliam is offline   Reply With Quote
Old 11-05-2011, 03:36 AM   #32
Supporting Vendor
Thread Starter
iTrader: (3)

emilio700's Avatar

Join Date: May 2005
Posts: 5,309
Total Cats: 1,329
Default

Quote:
Originally Posted by JasonC SBB View Post
Cool stuff!

What AFR's are you running?
12.8 through midrange, 13.0 on top. Cal is very finely tuned for economy.
Runs on CA91 pump gas.

Quote:
Originally Posted by Reverant View Post
Wow, that smartwire unit is really expensive. Unless someone uses all the channels it provides, it might be more economical to go with OTS solid state relays.
The difference is that the Smartwire is fully programmable, values can be displayed on dash, logic circuits can be set up (turn off lights when cranking, turn off fuel pump if fire system triggers, etc). You want the defroster to trip the "fuse" at exactly 13.5amps? No problem. You want it to reset after exactly 4.5 seconds, you bet. You want it to attempt reset no more than 3 times, OK. You want to datalog all system voltages, amps, switch status, it'll do that too. Want to set a warning light on the IQ3 dash if the fuel pump draws more the 7.6 amps for more than 2.3 seconds, sure.

The stuff the Smartwire will do is endless. It ain't cheap but you are going into a cutting edge OEM realm of power control for even a home built project car.
emilio700 is offline   Reply With Quote
Old 11-05-2011, 06:50 AM   #33
Senior Member

Join Date: Dec 2004
Location: Brisbane, Australia
Posts: 1,272
Total Cats: 32
Default

What is the matting in the driver's footwell? I need to get some of that as a bare floor is so freakin' slippery in the wet!
timk is offline   Reply With Quote
Old 11-05-2011, 11:57 AM   #34
Newb
iTrader: (1)

Join Date: Oct 2010
Posts: 19
Total Cats: 2
Default

Soooooo fired up to drive this car! Honored to be part of the the team with one of the BEST prepared enduro cars out there. I hope I can figure out what all those switches do...

Cheers,

Dean
deano is offline   Reply With Quote
Old 11-05-2011, 01:08 PM   #35
Elite Member

Join Date: Jul 2005
Posts: 6,454
Total Cats: 80
Default

Quote:
Originally Posted by emilio700 View Post
12.8 through midrange, 13.0 on top. Cal is very finely tuned for economy.
Runs on CA91 pump gas.
What kind of EGT's you seeing at the end of the main straight?

Did you guys do anything like run the exhaust cam retarded to help control EGT?
Or use Inconel exhaust valves?

Last edited by JasonC SBB; 11-05-2011 at 02:19 PM.
JasonC SBB is offline   Reply With Quote
Old 11-05-2011, 03:52 PM   #36
Junior Member
iTrader: (2)

Join Date: May 2008
Location: Bethalto, Il
Posts: 318
Total Cats: 2
Default

man that is a beast. What was done besides the intake to get the vvt to 148 whp. that seams like a very good power for a na bp motor.

high(er) comp pistons and tuning ? cams ?
turbotyla is offline   Reply With Quote
Old 11-05-2011, 04:00 PM   #37
Junior Member
iTrader: (1)

Join Date: Aug 2007
Posts: 387
Total Cats: 10
Default

Quote:
Originally Posted by saboteur View Post
What is the matting in the driver's footwell? I need to get some of that as a bare floor is so freakin' slippery in the wet!
that's a thermal mat. there are also some of that underneath the car also. but it also double as a friction pad.

you can get one of those stick on skateboard tape also.
bellwilliam is offline   Reply With Quote
Old 11-05-2011, 09:08 PM   #38
Junior Member

Join Date: Nov 2009
Location: SF, CA
Posts: 49
Total Cats: 2
Default

Quote:
Originally Posted by bellwilliam View Post
that's a thermal mat. there are also some of that underneath the car also. but it also double as a friction pad.
What brand are you using? I've heat soak issues in the driver's footwell, not during track day sessions but on the multi-hour drive to/from the event.
billybobster is offline   Reply With Quote
Old 11-05-2011, 10:58 PM   #39
Supporting Vendor
Thread Starter
iTrader: (3)

emilio700's Avatar

Join Date: May 2005
Posts: 5,309
Total Cats: 1,329
Default

Quote:
Originally Posted by saboteur View Post
What is the matting in the driver's footwell? I need to get some of that as a bare floor is so freakin' slippery in the wet!
The stuff in the floor is Koolmat. Still a bit slippery when wet but great in the dry.
The inside of the tunnel has Thermo-Tec adhesive backed barrier. Image here. Header and exhaust are wrapped to rear axle with DEI 2" header wrap. Car has almost no radiant heat inside. Putting a ton of thermal barriers on the cockpit side of the tunnel is a waste of time. Exhaust will heat all the sheet metal from the firewall to the rear bulkhead to 180 and radiate buckets of heat even if the little heel protector mat is saving your right foot. Keep the tub from getting hot in the first place and you don't need to go crazy in the interior.

Quote:
Originally Posted by deano View Post
Soooooo fired up to drive this car! Honored to be part of the the team with one of the BEST prepared enduro cars out there. I hope I can figure out what all those switches do...

Cheers,

Dean
We're honored to have you on the team Dean. For those of you who don't know who Dean is, he's one of the fastest Miata drivers in the country. There isn't anyone faster around Thunderhill IMO. I feel like we have a superteam with all the talent we have gathered.

Quote:
Originally Posted by JasonC SBB View Post
What kind of EGT's you seeing at the end of the main straight?

Did you guys do anything like run the exhaust cam retarded to help control EGT?
Or use Inconel exhaust valves?
Supertech SS valves and other measures. No EGT sensor which is an oversight on my part actually. We ran the motor ridiculously lean for quite a while in testing for. Oil, leakdown, compression and borescope all show no harm done. Experience has shown that our target AFR's are safe for a bone stock motor so we know we are good.

Quote:
Originally Posted by turbotyla View Post
man that is a beast. What was done besides the intake to get the vvt to 148 whp. that seams like a very good power for a na bp motor.

high(er) comp pistons and tuning ? cams ?
Stock junkyard USDM VVT motor will make 148whp with I/H/E and ECU on pump gas. JDM 10.5:1 motor with square top closer to 160whp with same bolt-ons.
emilio700 is offline   Reply With Quote
Old 11-05-2011, 11:26 PM   #40
I'm Miserable!
iTrader: (1)

Join Date: Jan 2008
Posts: 203
Total Cats: 8
Default

What size wheels/tire widths?

I'm planning on going this type of NA next year before heading into the boosted world. Should be a nice jump up from a 94 ECU controlled 97 motor. Need to know if I should order some 15x8s or 15x9s, haha.
GAMO is offline   Reply With Quote
