Old 01-22-2014, 08:31 PM   #361
I take big bites
iTrader: (1)

turbofan's Avatar

Join Date: Sep 2010
Location: Hurricane, UT
Posts: 6,930
Total Cats: 526
Default

I know it's of lower importance, but any feedback on fuel economy?
turbofan is offline   Reply With Quote
Old 01-23-2014, 10:03 AM   #362
Elite Member
iTrader: (2)

Join Date: Sep 2008
Location: Central Florida
Posts: 3,284
Total Cats: 178
Default

Quote:
Originally Posted by turbofan View Post
I know it's of lower importance, but any feedback on fuel economy?
Scrappy Jack is offline   Reply With Quote
Old 01-23-2014, 03:14 PM   #363
Supporting Vendor
iTrader: (31)

Savington's Avatar

Join Date: Nov 2006
Location: Sunnyvale, CA
Posts: 14,372
Total Cats: 1,338
Default

Quote:
Originally Posted by Scrappy Jack View Post
Empty quoting this
Savington is online now   Reply With Quote
Old 01-23-2014, 03:20 PM   #364
I take big bites
iTrader: (1)

turbofan's Avatar

Join Date: Sep 2010
Location: Hurricane, UT
Posts: 6,930
Total Cats: 526
Default

turbofan is offline   Reply With Quote
Old 01-23-2014, 03:46 PM   #365
Supporting Vendor

KMiata's Avatar

Join Date: Sep 2012
Posts: 445
Total Cats: 145
Default

Quote:
Originally Posted by turbofan View Post
I know it's of lower importance, but any feedback on fuel economy?
It's basically the same as the BP. Its hard to say for sure though because I've been beating on this thing non stop, plus I think the tune is a little rich. I'll know better once I do some long, boring highway driving.
KMiata is online now   Reply With Quote
Old 01-23-2014, 06:22 PM   #366
Elite Member
iTrader: (1)

Join Date: May 2009
Location: Jacksonville, FL
Posts: 4,687
Total Cats: 216
Default

Attached Thumbnails
K series Miata swap-page-bg.png

Last edited by Full_Tilt_Boogie; 01-25-2014 at 01:25 PM.
Full_Tilt_Boogie is offline   Reply With Quote
Old 01-24-2014, 12:00 PM   #367
Elite Member

Join Date: Dec 2008
Location: Colorado
Posts: 1,669
Total Cats: 36
Default

In for vid of stock long block K24a2 Miata with decent header and intake and tune v basic 225ish WHP 1.8 turbo Miata.

Yes, I know the turbo will have 35ish more WTQ.

Yes, I know the basic 1.8 is cheaper.

But it will be interesting to see how another thousand RPM allows the K24 car to use gearing more effectively. 5 or 6 speed on either car.

I bet its closer than one most are thinking. And the whole not-having-to-source-badass-hot-side-parts-to-keep-it-together-on-long-track-stints has be tempting for a fairly substantial contingent of people here. Imagine Crusher with a K24. Jesus. Lots of classes where that's not OK, but still.
Sparetire is offline   Reply With Quote
Old 01-24-2014, 12:44 PM   #368
Elite Member
iTrader: (3)

Join Date: Feb 2008
Location: Huntsville, AL
Posts: 1,882
Total Cats: 45
Default

My buddy has a Civic with a K20A2 that made 220whp on a heartbreaker dyno with a kludge intake, Hybrid swap header, 3" exhaust and a street tune on 93 octane. I want this in my life.

magicdc2, I need you to either finalize the swap parts or let me test a prototype kit. Like, right now. professional engineering insights and professional install photography can be provided. Serious.
vehicular is offline   Reply With Quote
Old 01-24-2014, 12:52 PM   #369
Junior Member

Join Date: Mar 2012
Posts: 322
Total Cats: 23
Default

Quote:
Originally Posted by vehicular View Post
magicdc2, I need you to either finalize the swap parts or let me test a prototype kit. Like, right now. professional engineering insights and professional install photography can be provided. Serious.
I haz the same feels.



But sadly I'm a college student, and my car is in the garage until the snows gone.. In a few months..
M.Adamovits is offline   Reply With Quote
Old 01-24-2014, 08:19 PM   #370
Supporting Vendor

KMiata's Avatar

Join Date: Sep 2012
Posts: 445
Total Cats: 145
Default

Quote:
Originally Posted by vehicular View Post
My buddy has a Civic with a K20A2 that made 220whp on a heartbreaker dyno with a kludge intake, Hybrid swap header, 3" exhaust and a street tune on 93 octane. I want this in my life.

magicdc2, I need you to either finalize the swap parts or let me test a prototype kit. Like, right now. professional engineering insights and professional install photography can be provided. Serious.
Almost there, thanks for being patient. Official pricing to be released really soon. I'm in Chicago, come on up and I'll let you drive it (also serious).
KMiata is online now   Reply With Quote
Old 01-24-2014, 08:24 PM   #371
Supporting Vendor

KMiata's Avatar

Join Date: Sep 2012
Posts: 445
Total Cats: 145
Default

Quote:
Originally Posted by Sparetire View Post
In for vid of stock long block K24a2 Miata with decent header and intake and tune v basic 225ish WHP 1.8 turbo Miata.

Yes, I know the turbo will have 35ish more WTQ.

Yes, I know the basic 1.8 is cheaper.

But it will be interesting to see how another thousand RPM allows the K24 car to use gearing more effectively. 5 or 6 speed on either car.

I bet its closer than one most are thinking. And the whole not-having-to-source-badass-hot-side-parts-to-keep-it-together-on-long-track-stints has be tempting for a fairly substantial contingent of people here. Imagine Crusher with a K24. Jesus. Lots of classes where that's not OK, but still.
That's what this swap is about - just good, cheap OEM power that stays nice and cool after lots of track abuse.
KMiata is online now   Reply With Quote
Old 01-31-2014, 07:26 PM   #372
Elite Member

Join Date: Dec 2008
Location: Colorado
Posts: 1,669
Total Cats: 36
Default

Just for kicks I looked around online a bit.

If someone did end up roasting 5 speeds using a K24, S2000 6 speeds run at like 600 bucks and a K series adaptor plate to run one is about 300 bucks.

'Why not just get a 6 speed?' Because they are a pita to find and expensive and they break sooner than S2000 boxes for the crazy power people. Stripping 4th because TQ on a road course in a 350WHP 2400LB car is sort of lame.

So basically this has possible transmission solutions that are sort of interesting. PPF and cross member issues aside, 1000ish for a 6 speed with useable ratios for a K that's pretty strong and shifts well is neato. S2000s run 4.10 gears, so the whole package should work pretty well.

Contrast this with finding one of those 'affordable' and 'common' T-56s I keep hearing about.
Sparetire is offline   Reply With Quote
Old 01-31-2014, 07:35 PM   #373
Junior Member

Join Date: Nov 2010
Location: Chicagoland
Posts: 160
Total Cats: 2
Default

U need a custom flywheel as well.

Custom drive shaft

And adaptor to go from pff to s2000 trans.
natedawg is offline   Reply With Quote
Old 01-31-2014, 07:51 PM   #374
Supporting Vendor

KMiata's Avatar

Join Date: Sep 2012
Posts: 445
Total Cats: 145
Default

Quote:
Originally Posted by Sparetire View Post
Just for kicks I looked around online a bit.

If someone did end up roasting 5 speeds using a K24, S2000 6 speeds run at like 600 bucks and a K series adaptor plate to run one is about 300 bucks.

'Why not just get a 6 speed?' Because they are a pita to find and expensive and they break sooner than S2000 boxes for the crazy power people. Stripping 4th because TQ on a road course in a 350WHP 2400LB car is sort of lame.

So basically this has possible transmission solutions that are sort of interesting. PPF and cross member issues aside, 1000ish for a 6 speed with useable ratios for a K that's pretty strong and shifts well is neato. S2000s run 4.10 gears, so the whole package should work pretty well.

Contrast this with finding one of those 'affordable' and 'common' T-56s I keep hearing about.
Yeah, as natedawg mentioned, here are the reasons I did not consider an S2000 trans:
-this setup is mainly designed to be used with an N/A K series setup, thus making less torque than you turbo BP guys, and fits within the power limits of the Miata trans
-S2000 trans is one more thing to buy
-doesn't bolt to PPF, so needs custom mounts or PPF adapter?
-custom drive shaft is needed
-VSS won't work, which means you'll probably have to run an S2000 cluster (my setup has 100% functional miata gauges)

Its certainly a good option for people wanting to make over 350wtq out of a K miata, but for me and probably 95% of potential buyers, the Miata trans will do nicely, keep costs down, and keep it simple.

So far my 5 speed trans is handling the K24 torque like a champ, and gearing feels good with the 4.3. I don't see much reason to make the setup any more complex.
KMiata is online now   Reply With Quote
Old 02-01-2014, 12:34 AM   #375
Newb

Join Date: Nov 2010
Posts: 28
Total Cats: 1
Default

What is different about the k-series engine that would require a custom k-member? Is it the oil pan and pickup?

Just wondering.
exST165 is offline   Reply With Quote
Old 02-01-2014, 01:28 PM   #376
Supporting Vendor

KMiata's Avatar

Join Date: Sep 2012
Posts: 445
Total Cats: 145
Default

Quote:
Originally Posted by exST165 View Post
What is different about the k-series engine that would require a custom k-member? Is it the oil pan and pickup?

Just wondering.
Its for clearance everywhere. header, oil pan, oil pump, etc.

Our first k member was a chopped OEM one, and we had to hack it up pretty drastically.
KMiata is online now   Reply With Quote
Old 02-11-2014, 02:50 PM   #377
Supporting Vendor

KMiata's Avatar

Join Date: Sep 2012
Posts: 445
Total Cats: 145
Default

copied and pasted from k20a.org thread, in case anyone is interested:

"I also have some important updates on the final production version of parts:

I have a revised version of the adapter plate, this time made in steel.

I have also revised the intake manifold adapters to be 3/4" thick, allowing customers to run a full OEM k series pulley setup with the EP3 idler (there was previously interference with the pulley and TB). Also, I have a version for a PRB head as well as a RBC head.

The subframe and mounts were shipped out this week to my supplier, and I will have the first final production versions in a few weeks, including powder coating.

I have contracted with Moroso to produce a custom baffled pan for me based on my specs. They already have my prototypes and will also be sending me a unit to test fit in the next few weeks."
KMiata is online now   Reply With Quote
Old 02-11-2014, 03:39 PM   #378
Senior Member
iTrader: (2)

Join Date: Oct 2011
Location: SE NM
Posts: 1,461
Total Cats: 48
Default

I just came.

However, wtf is a PRB and RBC head?

Also, I saw you like to PM people the guys on that other site the ballpark pricing. I would appreciate the same!
Chilicharger665 is offline   Reply With Quote
Old 02-11-2014, 04:10 PM   #379
Elite Member
iTrader: (1)

Join Date: May 2009
Location: Jacksonville, FL
Posts: 4,687
Total Cats: 216
Default

Quote:
Originally Posted by Chilicharger665 View Post
However, wtf is a PRB and RBC head?
Head casting codes:

PRB : 02-04 RSX Type S - 200HP
PRC : K20A (JDM Type R) - 220HP
PNA : CR-V
PND : Base model RSX
PNF : "EP3" Civic Si
RBB : TSX
RRB : 06+ Civic Si


PRB and PRC are good ones.
The PND/PNF head is really common and also really awful. It was rated at 160hp at the crank, but Im pretty sure that was an exaggeration since they struggle to make 120 at the wheels.

Last edited by Full_Tilt_Boogie; 02-11-2014 at 05:54 PM.
Full_Tilt_Boogie is offline   Reply With Quote
Old 02-11-2014, 08:56 PM   #380
Supporting Vendor

KMiata's Avatar

Join Date: Sep 2012
Posts: 445
Total Cats: 145
Default

Quote:
Originally Posted by Full_Tilt_Boogie View Post
Head casting codes:

PRB : 02-04 RSX Type S - 200HP
PRC : K20A (JDM Type R) - 220HP
PNA : CR-V
PND : Base model RSX
PNF : "EP3" Civic Si
RBB : TSX
RRB : 06+ Civic Si


PRB and PRC are good ones.
The PND/PNF head is really common and also really awful. It was rated at 160hp at the crank, but Im pretty sure that was an exaggeration since they struggle to make 120 at the wheels.
pretty much. and between all those heads, there are two basic designs for the coolant ports on the intake side.

TSX and Si use the RBB/RBC/RRB style, and the Type S/Type R uses the PRB/PRC heads (identical castings).

People still make 200whp out of the weak 160 hp k20a3 with OEM internals, so its not that hard to make power. I've never understood the point of using that motor, unless you are power limited in a specific class.
KMiata is online now   Reply With Quote
