Old 09-18-2012, 11:35 AM   #361
Senior Member
iTrader: (1)

Join Date: Jun 2006
Location: Sweden
Posts: 1,378
Total Cats: 59
Default

Quote:
Originally Posted by hustler View Post
What are the chances my FM cam gear has the stuff to run an NB CMP? I just ordered MS2 and I have no idea how to get a CMP sensor.
The Toda gears that FM have now are available in both forms (with and without nubs), just compare the pics with what you have
Flyin' Miata : Engine/Drivetrain : Internals : Toda adjustable cam gear
NiklasFalk is offline   Reply With Quote
Old 09-18-2012, 11:53 AM   #362
mkturbo.com
iTrader: (24)

shuiend's Avatar

Join Date: May 2006
Location: Charleston SC
Posts: 13,985
Total Cats: 1,198
Default

Can you really not buy a replacement VC? I know you have things welded onto yours, but that can be redone. Do you really want your timing belt exposed that much.

I am going to mail you one of these stickers.
Attached Thumbnails
Hustler's build thread 2.0, the natural aspiration connection-1330838337-na-best-sticker-blue.jpg
shuiend is offline   Reply With Quote
Old 09-18-2012, 12:12 PM   #363
Elite Member
iTrader: (10)

soviet's Avatar

Join Date: Jan 2010
Location: VA
Posts: 3,494
Total Cats: 260
Default

why can't you run a modified CAS and configure megasquirt for custom trigger wheel?
also, you can at least wear your neck restraint ...
soviet is offline   Reply With Quote
Old 09-18-2012, 12:22 PM   #364
Tour de Franzia
Thread Starter
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,055
Total Cats: 366
Default

Quote:
Originally Posted by NiklasFalk View Post
The Toda gears that FM have now are available in both forms (with and without nubs), just compare the pics with what you have
Flyin' Miata : Engine/Drivetrain : Internals : Toda adjustable cam gear
That's another $200 plus another valve cover that I'll also have to get an AN-fitting welded on. So we're basically looking at $400 to get a CMP signal.
hustler is offline   Reply With Quote
Old 09-18-2012, 12:26 PM   #365
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: NH
Posts: 9,213
Total Cats: 82
Default

You could just get a normal trigger wheel in the right diameter for like 60 bucks and make your own hall effect sensor bracket.
Leafy is offline   Reply With Quote
Old 09-18-2012, 12:38 PM   #366
Elite Member
iTrader: (10)

soviet's Avatar

Join Date: Jan 2010
Location: VA
Posts: 3,494
Total Cats: 260
Default

1) run your choice of trigger wheel - 4T, 12-1T, 36-1T
2) cut one tab off the CAS - so it sends ONE pulse per camshaft revolution (normally it sends two pulses - long one and short one, 180* apart)
3) run 1 wire from CAS for cam signal, run 1 wire from crank sensor for crank signal
soviet is offline   Reply With Quote
Old 09-18-2012, 12:40 PM   #367
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 73,917
Total Cats: 1,989
Default

still too hard for hussy.
Braineack is offline   Reply With Quote
Old 09-18-2012, 12:41 PM   #368
Tour de Franzia
Thread Starter
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,055
Total Cats: 366
Default

Quote:
Originally Posted by soviet View Post
1) run your choice of trigger wheel - 4T, 12-1T, 36-1T
2) cut one tab off the CAS - so it sends ONE pulse per camshaft revolution (normally it sends two pulses - long one and short one, 180* apart)
3) run 1 wire from CAS for cam signal, run 1 wire from crank sensor for crank signal
Where does that single-tooth fall in relation to the CKP #1 tooth?
hustler is offline   Reply With Quote
Old 09-18-2012, 09:41 PM   #369
Tour de Franzia
Thread Starter
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,055
Total Cats: 366
Default

Quote:
Originally Posted by Braineack View Post
still too hard for hussy.
I just want to be sure it starts the first day.
hustler is offline   Reply With Quote
Old 09-18-2012, 09:42 PM   #370
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 73,917
Total Cats: 1,989
Default

wheres the fun in that?
Braineack is offline   Reply With Quote
Old 09-18-2012, 09:46 PM   #371
Junior Member

Join Date: Sep 2010
Location: SFL
Posts: 375
Total Cats: 3
Default

the run of the mill BP05 distributor only has one tooth on the cam side, and is drop in.
MD323 is offline   Reply With Quote
Old 09-18-2012, 09:52 PM   #372
Tour de Franzia
Thread Starter
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,055
Total Cats: 366
Default

Does anyone have an EV14 injector timing table?
hustler is offline   Reply With Quote
Old 09-18-2012, 09:52 PM   #373
Tour de Franzia
Thread Starter
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,055
Total Cats: 366
Default

Quote:
Originally Posted by MD323 View Post
the run of the mill BP05 distributor only has one tooth on the cam side, and is drop in.
That tooth must fall be tween the last and first CKP tooth, that's the challenge. Any idea if those two jive?
hustler is offline   Reply With Quote
Old 09-18-2012, 09:58 PM   #374
Junior Member

Join Date: Sep 2010
Location: SFL
Posts: 375
Total Cats: 3
Default

your using the 12T crank wheel correct? ill check on the tooth angle tomorrow when im infront of the car.
MD323 is offline   Reply With Quote
Old 09-18-2012, 10:06 PM   #375
Tour de Franzia
Thread Starter
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,055
Total Cats: 366
Default

Quote:
Originally Posted by MD323 View Post
your using the 12T crank wheel correct? ill check on the tooth angle tomorrow when im infront of the car.
I'm running it exactly like this:
hustler is offline   Reply With Quote
Old 09-19-2012, 04:00 AM   #376
NB/VVT Connoisseur
iTrader: (24)

viperormiata's Avatar

Join Date: Aug 2008
Location: Key West
Posts: 6,099
Total Cats: 239
Default

viperormiata is offline   Reply With Quote
Old 09-19-2012, 04:36 AM   #377
Elite Member
iTrader: (2)

triple88a's Avatar

Join Date: Apr 2006
Location: Chicago, IL
Posts: 9,111
Total Cats: 624
Default

If that's to scale you need a bigger sensor.
triple88a is offline   Reply With Quote
Old 09-19-2012, 08:06 AM   #378
Elite Member
iTrader: (1)

Join Date: Jun 2006
Location: Warrington/Birmingham
Posts: 2,641
Total Cats: 40
Default

Quote:
Originally Posted by hustler View Post
That tooth must fall be tween the last and first CKP tooth, that's the challenge. Any idea if those two jive?
Between the first and last tooth, so 360 deg, or one complete revolution of the crank.

If the CMP tooth were to cross that it's have to be over 180deg in duration, (2 crank revs per 1 cam rev). Even the long pulse isn't that long, so you don't need to worry.
richyvrlimited is offline   Reply With Quote
Old 09-19-2012, 01:02 PM   #379
Tour de Franzia
Thread Starter
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,055
Total Cats: 366
Default

Quote:
Originally Posted by richyvrlimited View Post
Between the first and last tooth, so 360 deg, or one complete revolution of the crank.

If the CMP tooth were to cross that it's have to be over 180deg in duration, (2 crank revs per 1 cam rev). Even the long pulse isn't that long, so you don't need to worry.
I know this is going to be a shock to everyone on the forum, but I'm confused. Rather than interpret what you wrote, I'll just clarify my question.

I was under the impression the CMP tooth needed to fall between tooth #2 and tooth #3 on my special "Hellow Kitty" CKP set-up. Can it fall somewhere else and still work properly?
hustler is offline   Reply With Quote
Old 09-19-2012, 01:20 PM   #380
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: NH
Posts: 9,213
Total Cats: 82
Default

I know it can on haltech. You have to tell it how many degrees the trigger tooth on the crank is from tdc and how many degrees the trigger tooth on the cam is from the combustion stroke tdc. And whatever that amount of degrees is is the max timing advance you can run.
Leafy is offline   Reply With Quote
